Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
ZLQ
-
Model Number:
-
ZLQ16B-P10/E
-
Insulation Resistance:
-
>1000megohm
-
anbient temperature:
-
-20°-+55°
-
Electrical life:
-
More than 50000 times
Quick Details
-
Protection Level:
-
IP67/IK09
-
Max. Current:
-
3A/AC220V
-
Max. Voltage:
-
250V
-
Place of Origin:
-
China
-
Brand Name:
-
ZLQ
-
Model Number:
-
ZLQ16B-P10/E
-
Insulation Resistance:
-
>1000megohm
-
anbient temperature:
-
-20°-+55°
-
Electrical life:
-
More than 50000 times
Product Description
| Project | Parameter | Project | Parameter |
| Switch type | slow moving doubie contact | Explosion-proof grade | Ik09for metal) |
| contact resistance | ≤50mΩ | Operating pressure | About 2.5N |
| Insulation resistance | ≥ 1000MΩ | Operating limits | Connect about 0.9mm, total stroke about 3mm |
| Dielectric strength | 1000vAC | Nut torque | 5 ~14N.m |
| The environment temperature | -20°c~+55°c | The shell | Stainless steel/ brass nickel plated |
| Electrical life | More than 10000times | The keys | Stainless steel/ brass nickel plated |
| Mechanical life | More than 500000 times | base | Engineering plastics |
| Waterproof level | IP67 | contact | Gold-plated/gold |
