Huahang Fast delivery High Pressure Hydraulic Filter cartridge Melt Hydraulic Oil Filter Element for oil purification

Huahang Fast delivery High Pressure Hydraulic Filter cartridge Melt Hydraulic Oil Filter Element for oil purification

FOB Reference Price: Get Latest Price

≥2 Pieces

US $43

≥100 Pieces

US $42

≥500 Pieces

US $38

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Weight:: 1.2 kg

Dimension(L*W*H):: customized

Product name:: High quality polymer stainless steel melt blown filter element

Filter material:: 316/304 stainless steel mesh

Filter Type:: oil melt filter cartridge

Working medium:: hydraulic oil

Working pressure:: 25MPa

Filtration rate:: 230 mesh

Flow Rate:: 70 L/min

After Warranty Service:: Online support

end cover material:: stainless steel

Quick Details

Core Components:: oil melt filter

Place of Origin:: Henan, China

Brand Name:: HUAHANG

Weight:: 1.2 kg

Dimension(L*W*H):: customized

Product name:: High quality polymer stainless steel melt blown filter element

Filter material:: 316/304 stainless steel mesh

Filter Type:: oil melt filter cartridge

Working medium:: hydraulic oil

Working pressure:: 25MPa

Filtration rate:: 230 mesh

Flow Rate:: 70 L/min

After Warranty Service:: Online support

end cover material:: stainless steel

Product Description

Huahang Fast delivery High Pressure Hydraulic Filter cartridge Melt Hydraulic Oil Filter Element for oil purification

Candle filter also named the melt filter element, is mainly used for high temperature, high pressure, high viscosity polymer, polyester melt filtration. The filter upper and lower end caps are made of stainless steel to ensure corrosion resistance. The filter medium is made of stainless steel fiber sintered felt and stainless steel wire braided mesh is folded and corrugated. The dimensions are small and the filter area is large. It can be cleaned repeatedly.With the pore gradient formed by layers of different pore sizes,the stainless steel sintered fiber felt product can achieve higher rating and larger holding capacity. Stainless steel folding filter element, also
known as melt filter element,its filter layer is made of stainless steel sintered felt,which is a kind of porous depth filter material made of stainless steel fiber sintered at high temperature,Sintered mesh filter is several layers of metal mesh sintered together to form a porous metal filter. Sintered mesh filter is several layers of metal mesh sintered together to form a porous metal filter.
