Quick Details
-
Model Number:
-
LT3500
-
Voltage:
-
110V
-
Rated Power:
-
7.5kw
-
Dimension(L*W*H):
-
259*152.4*230mm
-
Weight (KG):
-
8kgs
-
Year:
-
2014
-
Input Voltage:
-
110 V~125V ±10%, 1-PH, 50/60Hz
-
Input Current:
-
30A
-
Ambient Temperature:
-
-10~40°C
-
Working Environment Humidity:
-
≤90%
-
Cutting Material:
-
Mild Steel; Stainless Steel; Aluminum
-
Maximum Severance Cutting Thickness:
-
15mm
-
Rated Duty Cycle:
-
35% @35A
-
Pilot Arc Start Mode:
-
High Frequency
-
Recommended Pressure/Flow Rate:
-
0.6~0.75Mpa 3.0scfm @70psi
-
Gas Supply:
-
Clean, dry, oil-free air
-
Certification:
-
CE; FC
Quick Details
-
Dimensions:
-
47*27*35cm
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Lotos
-
Model Number:
-
LT3500
-
Voltage:
-
110V
-
Rated Power:
-
7.5kw
-
Dimension(L*W*H):
-
259*152.4*230mm
-
Weight (KG):
-
8kgs
-
Year:
-
2014
-
Input Voltage:
-
110 V~125V ±10%, 1-PH, 50/60Hz
-
Input Current:
-
30A
-
Ambient Temperature:
-
-10~40°C
-
Working Environment Humidity:
-
≤90%
-
Cutting Material:
-
Mild Steel; Stainless Steel; Aluminum
-
Maximum Severance Cutting Thickness:
-
15mm
-
Rated Duty Cycle:
-
35% @35A
-
Pilot Arc Start Mode:
-
High Frequency
-
Recommended Pressure/Flow Rate:
-
0.6~0.75Mpa 3.0scfm @70psi
-
Gas Supply:
-
Clean, dry, oil-free air
-
Certification:
-
CE; FC
The LOTOS LT3500 Plasma Cutter is designed for light cutting projects. This unit is the most compact plasma cutter one can find in the market and weights only 8kg (17.6lbs). In the meantime, this powerful unit is powerful enough to cut 10mm (2/5inch) metal with 15mm (3/5inch) severance thickness, making it an ideal choice for cost conscious DIY hobbyists. The LT3500 is similar to the LT3200 except it has a higher amperage range up to 35 A under 110 V, has a pre-installed air filter and air gauge ready to be connected your air compressor with the stand NPT 1/4” industry type D coupler (can be setup quickly within 2 minutes).
- 35 Amp digital inverter plasma cutter
- 110V Automatic dual frequency (50/60Hz) Can easily be connected to your existing 110V wall outlet
- NPT 1/4" industry type D coupler on your air compressor to connect the plug pre-installed on the machine. The whole machine can be setup quickly within 1 minute.
- Compact size, ultimate portability and efficient cooling fan system.
- Suitable for: Stainless Steel, Alloy Steel, Mild Steel, Copper, Aluminum, etc.
Packing Details:
- 1 set/carton
- Cardboard carton with plastic bag and foam inside
Delivery Details:
- Within 20 days after confirming the payment
- 3-5 workdays shipping from China by Air/Express (DHL, FedEx, UPS, EMS, etc.)
- We could also arrange shipment by sea(About 20-25 days to Europe or North America). Minimum CBM: 1 CBM
