Quick Details
-
Warranty:
-
25 Years
-
Brand Name:
-
Sunpal
-
Model Number:
-
SP425M-54H
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1722 x 1134 x 30mm
-
Keyword:
-
Half Cell All Black Mono Solar Panel
-
Number of Cells:
-
108 Cells (6x18)
-
Weight:
-
20.8kg
-
Front Side Glass:
-
High transparency solar glass 3.2mm
-
Backsheet:
-
Black
-
Junction Box:
-
IP68 Rated, 3 Diodes
-
Cable:
-
MC Compatible
-
Frame:
-
Black, anodized aluminium alloy
-
Connector:
-
MC Compatible
-
Wind/Snow Load:
-
2400Pa/5400Pa
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, All Black, HJT, N-TYPE, TOPCON
-
Panel Efficiency:
-
21.76%
-
Warranty:
-
25 Years
-
Brand Name:
-
Sunpal
-
Model Number:
-
SP425M-54H
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1722 x 1134 x 30mm
-
Keyword:
-
Half Cell All Black Mono Solar Panel
-
Number of Cells:
-
108 Cells (6x18)
-
Weight:
-
20.8kg
-
Front Side Glass:
-
High transparency solar glass 3.2mm
-
Backsheet:
-
Black
-
Junction Box:
-
IP68 Rated, 3 Diodes
-
Cable:
-
MC Compatible
-
Frame:
-
Black, anodized aluminium alloy
-
Connector:
-
MC Compatible
-
Wind/Snow Load:
-
2400Pa/5400Pa
Product Description
|
Maximum Power (Pmax/W)
|
405
|
|
410
|
415
|
|
420
|
|
425
|
|||||||
|
Open Circuit Voltage (Voc/V)
|
37.06
|
|
37.14
|
37.22
|
|
37.3
|
|
37.38
|
|||||||
|
Short Circuit Current (Isc/A)
|
13.85
|
|
13.92
|
13.99
|
|
14.06
|
|
14.13
|
|||||||
|
Voltage at Maximum Power (Vmp/V)
|
30.52
|
|
30.62
|
30.72
|
|
30.82
|
|
30.92
|
|||||||
|
Current at Maximum Power (Imp/A)
|
13.27
|
|
13.39
|
13.51
|
|
13.63
|
|
13.75
|
|||||||
|
Module Efficiency(%)
|
20.75
|
|
21
|
21.26
|
|
21.51
|
|
21.76
|
|||||||
|
Temperature Coefficient of Isc
|
+0.04%/°C
|
|
|
|
|
|
|
|
|||||||
|
Temperature Coefficient of Voc
|
-0.25%/°C
|
|
|
|
|
|
|
|
|||||||
|
Temperature Coefficient of Pmax
|
-0.34%/°C
|
|
|
|
|
|
|
|
|||||||
