J4 series servo motor (HG-JR medium and large capacity and low inertia series) HG-JR103 HG-JR153 HG-JR203 HG-JR353 Servo motor

Product name

Servo motor

Application

industrial automation

Item number

HG-JR103 HG-JR153 HG-JR203 HG-JR353

Type

Motor single

Response frequency

2.5KHZ

voltage specification

AC200 specification

Power

three-phase

Resolution

22 bit

Servo motor type

mid inertia

Angle flange size A (mm)

90/130

Rated torque(N・m)

3.2/4.8/6.4/10.5

consists

Controlled device Output sensor Feedback system

electromagnetic brake

without

Product Overview

MITSUBISHI J4 series servo motor (HG-SR medium capacity and medium inertia series)

The new J4 series not only inherits the high performance and high reliability of the J3 series midwife, but also makes further
improvements beyond imagination

Product Features

The MELSERV0-J4 series is equipped with the highest speed in the industry with a response frequency of 2.5KHZ

The SSC control application is extended from 8 to 16 axes. The high servo gain adjustment function can realize one-button
adjustment and vibration suppression control.

Medium inertia, medium capacity. Fully closed self-cooling (protection class: IP65)

Air environment: indoor (no direct sunlight), no corrosive gas, combustible gas, oil mist and dust

Control mode selection of servo motor

Torque control

Torque control mode is to set the size of the output torque of the motor shaft through the input of external analog or direct
address assignment. Specifically, for example, if 10V corresponds to 5Nm, the output of the motor shaft is 2.5Nm when the external
analog is set to 5V: if the motor shaft load is lower than 2.5Nm, the motor is rotating. The motor does not turn when the external
load is equal to 2.5Nm, and inverts when the external load is greater than 2.5Nm (usually generated in the case of gravity load).

It can change the set torque size by changing the setting of the analog quantity in real time, and also can change the value of
the corresponding address by means of communication. It is mainly used in winding and unwinding devices that have strict
requirements on the force of the material, such as wire raving devices or fiber pulling devices. The torque setting should be
changed at any time according to the change of the winding radius to ensure that the force of the material will not change with
the change of the winding radius.

Position control

The position control mode is generally determined by the frequency of the external input pulse to determine the rotation speed,
the number of pulses to determine the Angle of rotation, and some servos can directly assign the speed and displacement through
communication.

Because the position mode can have a very strict control of both speed and position, it is generally applied to positioning
devices.

Speed Mode

The rotation speed can be controlled by the input of analog quantity or the frequency of pulse. The speed mode can also be
positioned when the outer loop PID control device is equipped with the upper control device, but the position signal of the motor
or the position signal of the direct load must be given to the upper feedback for calculation.

At this time, the encoder at the motor shaft end only detects the motor speed, and the position signal is provided by the direct
detection device at the final load end. The advantage of this method is that the error in the intermediate transmission process
can be reduced and the positioning accuracy of the whole system can be increased.

Full closed-loop control mode: full closed-loop control is relative to semi-closed-loop control.

First let us understand the lower half closed loop control, half closed loop is the exponential control system or PLC to issue
speed pulse command. In the process of execution, the encoder of the servo itself feeds back the position to the servo, and the
servo itself corrects the deviation. The error of the servo itself can be avoided, but the mechanical error cannot be avoided,
because the control system does not know the actual position.

Fully closed loop means that the servo receives the pulse command of controllable speed from the upper controller, and the servo
receives the signal to execute. In the process of execution, there is a position feedback device on the mechanical device, which
is directly fed back to the control system. The control system judges the deviation from the actual by comparison, and gives the
servo instructions to correct the deviation. In this way, the control system completes the speed loop control of the servo through
the frequency controllable pulse signal, and then completes the position loop control of the servo through the position sensor
(grating scale, encoder). This control mode that combines the servo motor, motion controller and position sensor is called full
closed-loop control.
