Quick Details
-
Weight:
-
6000 kg
-
Motor power:
-
30kW
-
Torque:
-
89kN.m
-
Revolution:
-
0-2.8-3.9r/min
-
Force per cylinder:
-
480kN
Quick Details
-
Marketing Type:
-
New Product
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
XCM G
-
Weight:
-
6000 kg
-
Motor power:
-
30kW
-
Torque:
-
89kN.m
-
Revolution:
-
0-2.8-3.9r/min
-
Force per cylinder:
-
480kN
Hot Links
Product Description
| Description | Unit | Parameter value | |
| Pipe diameter | ID | mm | Φ1000 |
| OD | Φ1200 | ||
| Extend diameter | mm | Φ1100 | |
| Φ1200 | |||
| Outer diameter× length | mm | Φ1220×3600 | |
| Cutting wheels | Motor power | kW | 15×2 |
| Torque | kN.m | 89 | |
| Revolution | r/min | 0-2.8-3.9 | |
| Roll correction system | Force per cylinder | kN | 480 |
| Cylinder number | EA | 3 | |
| Steering angle | ° | 3 | |
| Motor power | kW | 2.2 | |
| slurry line diameter | mm | Φ100 | |
| Total power | kW | 47.2 | |
| Weight | kg | 6000 | |
| Jacking cylinders | Thrust | kN | 1500 |
| Number | EA | 2 | |
| Stroke | mm | 1250×2 | |
| Charge pump Motor power | kW | 22 | |
| Discharge pump Motor power | kW | 22 | |
| Injection pump Motor power | kW | 11 | |
Packaging & Shipping
We supervise the process from the factory to the port designated by the customer to ensure that the customer's products arrive at the destination accurately and safely.
