Quick Details
-
Max. Resolution:
-
384dots/line
-
Brand Name:
-
FENGYIJIE
-
Model Number:
-
FYJ-58DMI
-
Place of Origin:
-
Guangdong, China
-
Paper type:
-
themral paper roll
-
Application:
-
surpermarket, restaurant, retail shop, lottery, gas station, etc.
-
Command:
-
ESC\POS
-
Barcode:
-
Support to print barcode and qr code
-
Product name:
-
58mm Thermal Receipt Printer
-
Paper width:
-
57.5±0.5mm
-
Print Width:
-
48mm
-
Speed:
-
90mm/s
-
Print Density:
-
203Dpi
-
Weight:
-
About 350g
Quick Details
-
Max Paper Size:
-
58mm
-
Black Print Speed:
-
90mm/s
-
Color Print Speed:
-
null
-
Max. Resolution:
-
384dots/line
-
Brand Name:
-
FENGYIJIE
-
Model Number:
-
FYJ-58DMI
-
Place of Origin:
-
Guangdong, China
-
Paper type:
-
themral paper roll
-
Application:
-
surpermarket, restaurant, retail shop, lottery, gas station, etc.
-
Command:
-
ESC\POS
-
Barcode:
-
Support to print barcode and qr code
-
Product name:
-
58mm Thermal Receipt Printer
-
Paper width:
-
57.5±0.5mm
-
Print Width:
-
48mm
-
Speed:
-
90mm/s
-
Print Density:
-
203Dpi
-
Weight:
-
About 350g
Product Description
|
Printing method
|
line type direct thermal
|
|
Paper output method
|
Friction upward paper
|
|
Printing width
|
48mm (paper width 57.5±0.5mm)
|
|
Printing speed
|
90mm/s(MAX)
|
|
Printing density
|
384 dots/line (203 DPI)
|
|
Printing life
|
>50km
|
|
Built-in characters
|
Western: 192 international characters, 69 international code pages
Simplified Chinese: GB18030 national standard font library, supports common and uncommon characters Traditional Chinese: Big5 Support custom characters and Chinese characters |
|
Default line spacing
|
3.75mm=30/203 inches, line spacing supports setting in increments of 1/203 inches
|
|
Print command
|
ESC/POS command (see programming manual for details)
|
|
Bar code system
|
One-dimensional code: UPC-A, UPC-E, CODE39, CODE93, CODABAR, CODE128, ITF, EAN8(JAN8),
EAN13 (JAN13) QR code: QRCode (optional) |
|
Print bitmap
|
Support different density bitmap printing and NV Logo bitmap storage printing (storage space 60KBytes)
|
|
Detection function
|
Photoelectric sensor detects paper, thermal sensor temperature control protects print head
|
|
Operation Indication
|
Touch key power switch, touch key feed, power indicator and error indicator
|
|
Print interface
|
TTL serial port (COM port)
USB2.0 (USB printing support) Parallel port (LPT port) |
|
Cash drawer interface
|
12V-1A, 1 channel
|
|
Receive buffer
|
4KBytes
|
|
Paper Requirements Type:
|
Thermal Roll Paper
Width: 57.5±0.5mm Outer diameter: 60mm |
|
Dimensions
|
132*115*63mm
|
|
Body weight
|
0.35kg
|
|
Environmental requirements
|
Working environment: temperature 0～45℃,
Humidity 20%RH～85%RH (non-condensing) Storage environment: temperature -20～60℃, Humidity 5%RH～95%RH (non-condensing) |
|
Power requirements
|
Input voltage: 9.6-28V (voltage range depends on hardware version)
Input power: 24W, peak power 60W |
|
Reliable performance
|
MCBF > 5 million lines
|
