Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
TDER
-
Dimension(L*W*H):
-
3100*1440*1630
-
Weight:
-
570 KG, 570kg
-
After-sales Service Provided:
-
Overseas third-party support available
-
Controller:
-
Chinese controller
-
Load Center:
-
500mm
-
Item:
-
Harvest
Quick Details
-
Number of Rows:
-
3
-
Working Width(mm):
-
1100 mm
-
Tractor Power(HP):
-
40 - 120 HP
-
Place of Origin:
-
China
-
Brand Name:
-
TDER
-
Dimension(L*W*H):
-
3100*1440*1630
-
Weight:
-
570 KG, 570kg
-
After-sales Service Provided:
-
Overseas third-party support available
-
Controller:
-
Chinese controller
-
Load Center:
-
500mm
-
Item:
-
Harvest
Product parameters
|
Model No.
|
parameter
|
unit
|
specification
|
|
ZTH100
|
Model style
|
MM
|
Triangle crawler
|
|
|
Size(Length*Width*Height)
|
KG
|
3100*1440*1630
|
|
|
Weight(KG)
|
MM
|
570
|
|
|
Cutting width(MM)
|
MM
|
1100
|
|
|
Min ground clearance(MM)
|
MM
|
190
|
|
|
Average ground pressure(KPA)
|
KPA
|
10.9
|
|
|
Feeding volume(KG/S)
|
KG/S
|
1
|
|
|
Gear shift
|
/
|
1,2,0,-1
|
|
|
Engine model
|
/
|
KD195FB DIESEL
|
|
|
Rated power(KW)
|
KW
|
7.5
|
|
|
Power/RPM
|
R/MIN
|
3600
|
|
|
Start method
|
/
|
Electric start
|
|
|
Fuel
|
/
|
Diesel
|
FAQ
1. Why choose us?
As a manufacturer, TDER industrial is committed to offer not only products with high quality and performance and competitive price, but also in-time delivery and comprehensive after-services.
2. What is the product range of our factory ?
TDER industrial is a large machinery manufacturing enterprise that mainly supplies forklifts, loaders, excavators, and related accessories. We can also customize non-standard products according to customer requirements.
3. What payment terms can we accept?
Normally 30% deposit is required in advance, 70% balance shall be settled before shipment. And 100% irrevocable L/C at sight with the terms we agreed can also be accepted.
4. What Certificates do we have?
All products meet with the ISO9001 Quality System and have acquired CE certificate. Certificate of compliance with EPA, Euro 3 and Euro 5 engine emission approvals.
5. How about our delivery time?
Usually it will take 15 to 30 days after receiving your deposit. About standard products, we always have in stock and can deliver immediately. But customized products will take more time, depending on the requirements of your order.
6. Can we provide OEM service?
TDER industrial can provide customized products according to customers’ requirements, both OEM and ODM are acceptable.
