XLPE / PVC Steel Wire Armored Copper Power Cable 3x240mm2 Low Voltage Power Cable
XLPE / PVC Steel Wire Armored Copper Power Cable 3x240mm2 Low Voltage Power Cable
XLPE / PVC Steel Wire Armored Copper Power Cable 3x240mm2 Low Voltage Power Cable
XLPE / PVC Steel Wire Armored Copper Power Cable 3x240mm2 Low Voltage Power Cable
XLPE / PVC Steel Wire Armored Copper Power Cable 3x240mm2 Low Voltage Power Cable
XLPE / PVC Steel Wire Armored Copper Power Cable 3x240mm2 Low Voltage Power Cable
XLPE / PVC Steel Wire Armored Copper Power Cable 3x240mm2 Low Voltage Power Cable
XLPE / PVC Steel Wire Armored Copper Power Cable 3x240mm2 Low Voltage Power Cable

XLPE / PVC Steel Wire Armored Copper Power Cable 3x240mm2 Low Voltage Power Cable

FOB Reference Price: Get Latest Price
≥500 Meters
US $55
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Jacket:
PVC
Place of Origin:
Zhejiang, China
Brand Name:
ZGHQDL
Model Number:
Armored Copper Power Cable 3x240mm2
Description:
XLPE / PVC Steel Wire Armored Copper Power Cable 3x240mm2
Rated temperature:
70'C
Conductor material:
Tinned or plain copper
Core Identification:
Strips or insulations of different colors
Rated Voltage:
600/1000V

Quick Details

Insulation Material:
Xlpe
Application:
Underground
Conductor Material:
Copper
Jacket:
PVC
Place of Origin:
Zhejiang, China
Brand Name:
ZGHQDL
Model Number:
Armored Copper Power Cable 3x240mm2
Description:
XLPE / PVC Steel Wire Armored Copper Power Cable 3x240mm2
Rated temperature:
70'C
Conductor material:
Tinned or plain copper
Core Identification:
Strips or insulations of different colors
Rated Voltage:
600/1000V

Standard : IEC 60502

Application

XLPE / PVC Steel Wire Armored Copper Power Cable 3x240mm2 is used for fixed installations of rated voltages 1kV and below, such as distrubution networks or industrial installations. It can be installed in cable duct, trench or directly buried in earth. Steel wire armor allows the cable to bear considerable mechanical pressures.

Product Description

1) Rated Voltage: 600/1000V

2) Max. working temperature: 90 °c

3) Max. temperature during short circuit (≤5S): 250 °c

4) Conductor: stranded copper, tinned or plain

5) Shape of conductor: sectional

6) Sectional area: 240mm2

7) Insulation / thickness: XLPE / 1.7mm

8) No. of cores: 3

9) Armor: steel wire

10) Oversheath / thickness: PVC / 2.9mm

11) Approx. overall dia.: 56 mm

12) Min. beding radius: 12 times cable radius (multi-core ones)

13) Approx. weight: 10073kg/km

14) Max. conductor DC resistance at 20 °c: 0.0754 Ω/km (plain copper), 0.0762 Ω/km (tinned copper)
