STANDARD ACCESSORIES
✔
PART:INSTALL ON THE LATHE
✔
3-jaw chuck(Φ250mm)
✔
Steady rest & follow rest
✔
Work lamp
✔
Coolant system
✔
Full-length splash guard
✔
Foot brake and brake ribbon
✔
PART:INSIDE THE PACKAGE WITH THE LATHE
✔
4-jaw chuck(Φ320mm)
✔
Paddings
✔
Change gears
✔
Dead centre and centre sleeve
✔
Oil gun
✔
One whole set spanner
✔
Operation manual
- Product Details
- {{item.text}}
Quick Details
-
Max. Spindle Speed (r.p.m):
-
1600 r.p.m
-
Width of bed (mm):
-
350 mm
-
Spindle Motor Power(kW):
-
7.5
-
Max. Turned Length (mm):
-
2000
-
Travel (X Axis)(mm):
-
130 mm
-
Travel (Z Axis)(mm):
-
2000 mm
-
Place of Origin:
-
Jiangsu, China
-
Dimension(L*W*H):
-
2900*1150*1850MM
-
Brand Name:
-
SIECC / EDWARDS PEARSON
-
Model Number:
-
LC560/1500&2000MM
-
Voltage:
-
380V/50HZ/3PH
-
Weight (KG):
-
2550
-
Marketing Type:
-
Hot Product 2022
-
CNC or Not:
-
CNC
-
Automatic Grade:
-
Automatic
-
Certification:
-
CE/ISO/SGS/GOST
Quick Details
-
Type:
-
Horizontal
-
Max. Length of Workpiece (mm):
-
2000
-
Year:
-
2022
-
Max. Spindle Speed (r.p.m):
-
1600 r.p.m
-
Width of bed (mm):
-
350 mm
-
Spindle Motor Power(kW):
-
7.5
-
Max. Turned Length (mm):
-
2000
-
Travel (X Axis)(mm):
-
130 mm
-
Travel (Z Axis)(mm):
-
2000 mm
-
Place of Origin:
-
Jiangsu, China
-
Dimension(L*W*H):
-
2900*1150*1850MM
-
Brand Name:
-
SIECC / EDWARDS PEARSON
-
Model Number:
-
LC560/1500&2000MM
-
Voltage:
-
380V/50HZ/3PH
-
Weight (KG):
-
2550
-
Marketing Type:
-
Hot Product 2022
-
CNC or Not:
-
CNC
-
Automatic Grade:
-
Automatic
-
Certification:
-
CE/ISO/SGS/GOST
Product Overview
SIECC & Hectmac Machine Group
SIECC MACHINE @Hectmac Machinery GROUP
✔ A famous and leading manufactory for sheet metal fabrications machines
✔ With 20 years industry-area experiences specially in shearing machine,press brake,rolling ,lathe,milling,laser and plasma
cutting machines
✔ A mass of far-flung agents and partners globally
✔ CE ,UKCA ,Saudi Arabia,Russia certification and also Edwards Pearson European quality standard.
✔ 70 Years history brand Edwards Pearson European Brand
✔ The best timely and responsible service company in machinery area
✔ A team of professional technician team in China and oversea
✔ Reliable technicial guidance
✔ High technology self-design and structure update with innovation
✔ Edwards Pearson and SIECC ,strongly-recommended brand and partners by the worldwide clients and agents.
✔ Customer-oriented design ,OEM and service
✔ Dramatical achievement cooperation and collaboration
✔ A famous and leading manufactory for sheet metal fabrications machines
✔ With 20 years industry-area experiences specially in shearing machine,press brake,rolling ,lathe,milling,laser and plasma
cutting machines
✔ A mass of far-flung agents and partners globally
✔ CE ,UKCA ,Saudi Arabia,Russia certification and also Edwards Pearson European quality standard.
✔ 70 Years history brand Edwards Pearson European Brand
✔ The best timely and responsible service company in machinery area
✔ A team of professional technician team in China and oversea
✔ Reliable technicial guidance
✔ High technology self-design and structure update with innovation
✔ Edwards Pearson and SIECC ,strongly-recommended brand and partners by the worldwide clients and agents.
✔ Customer-oriented design ,OEM and service
✔ Dramatical achievement cooperation and collaboration
FEATURES AT A GLANCE
✔
THE SURFACE OF THE BEDWAYS IS SUPERSONIC FREQUENCY HARDENED AND PRECISION GRINDING.
✔
GEARS PRECISELY GROUND TO REDUCE NOISE.
✔
SPINDLE BORE 80MM.
✔
NO NEED FOR CHANGE GEAR.THE MACHINE CAN TRUN KINDS OF METRIC, INCH, MODULE AND D.P. THREADS.
Left elevation
PRODUCT SPECIFICATIONS
|
No
|
Item
|
Data
|
LC560/1500MM&LC560/2000MM
|
|
1
|
CAPACITY
|
Max.swing over bed
|
560mm
|
|
2
|
Max.swing over cross slide
|
Max.swing over cross slide
|
355mm
|
|
3
|
|
Max.swing over gap
|
785mm
|
|
4
|
|
Effective length of gap
|
200mm
|
|
5
|
|
Center Distance
|
1500/2000mm
|
|
6
|
|
Bed Width
|
350mm
|
|
2
|
HEADSTOCK
|
Spindle hole
|
80mm(105mm for optional)
|
|
8
|
Max. torque
|
Spindle nose
|
ISO-D8
|
|
|
|
Spindle taper
|
MT8
|
|
3
|
FEEDS AND THREADS
|
Max.travel of top slide
|
130mm
|
|
|
|
Max.travel of cross slide
|
310mm
|
|
|
|
Max.size of toolshank
|
25*25m2
|
|
|
|
Metric threads range
|
47kinds 0.2-14mm
|
|
|
|
Inch threads range
|
60kinds 2-112T.P.I
|
|
|
|
Longitudinal metric feeds
|
35kinds 0.059-1.646mm/rev
|
|
|
|
Longitudinal inch feeds
|
35kinds 0.0022-0.0612inc/rev
|
|
|
|
Cross metric feeds
|
35kinds 0.020-0.573mm/rev
|
|
|
|
Cross inch feeds
|
35kinds 0.00048-0.01354inc/rev
|
|
|
|
Moudle threads range
|
39kinds 0.1-7mπ
|
|
|
|
Diametral threads range
|
50kinds 4-112D.P
|
|
4
|
TAILSTOCK
|
Dia.of tailstock sleeve
|
75mm
|
|
|
|
Taper of tailstock sleeve
|
MT5
|
|
|
|
Max.travel of tailstock
|
180mm
|
|
5
|
MOTOR
|
Main drive motor
|
7.5KW
|
|
|
|
Coolant pump motor
|
90W
|
|
6
|
PACKING
|
LXWXH
|
290*115*185cm
|
|
7
|
WEIGHT
|
N.W/G.W
|
2250/2550KGS
|
PRODUCT CONFIGURATION
