grapple weight: 240kg
Rotator - GR100F ( Flange type)
rotator weight: 64kg
- Product Details
- {{item.text}}
Quick Details
-
Condition:
-
new
-
Weight:
-
290
-
Suitable Excavator(ton):
-
5-8 Ton
-
Max Jaw Opening:
-
1610mm
-
Product name:
-
Hydraulic Log Grapple for Excavator
-
rotation angle:
-
unlimited
-
Max rotation pressure:
-
250Bar
-
Max working pressure grapple closed:
-
300 Bar
-
Rotator:
-
DRB100 Flange type
-
Connections:
-
G1/4"
-
Max oil flow:
-
10lpm
-
Model:
-
LX36(T36)
-
Grapple jaw opening:
-
1580-1610mm
-
Material:
-
NM400
Quick Details
-
Marketing Type:
-
Hot Product 2022
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HOMIE
-
Condition:
-
new
-
Weight:
-
290
-
Suitable Excavator(ton):
-
5-8 Ton
-
Max Jaw Opening:
-
1610mm
-
Product name:
-
Hydraulic Log Grapple for Excavator
-
rotation angle:
-
unlimited
-
Max rotation pressure:
-
250Bar
-
Max working pressure grapple closed:
-
300 Bar
-
Rotator:
-
DRB100 Flange type
-
Connections:
-
G1/4"
-
Max oil flow:
-
10lpm
-
Model:
-
LX36(T36)
-
Grapple jaw opening:
-
1580-1610mm
-
Material:
-
NM400
T36 Log grapple usually equipped with GR100F rotator
Main models
Specifications
Rotators for choice
|
No
|
Item
|
GR30F
|
GR50F
|
GR60F
|
GR100F
|
GR120F
|
GR160F
|
|
1
|
Rotation angle
|
unlimited
|
unlimited
|
unlimited
|
unlimited
|
unlimited
|
unlimited
|
|
2
|
Max rotation pressure
|
250 bar
|
250 bar
|
250 bar
|
250 bar
|
250 bar
|
250 bar
|
|
3
|
Max working pressure(closed)
|
300 bar
|
300 bar
|
300 bar
|
300 bar
|
300 bar
|
300 bar
|
|
4
|
Capacity
|
330cm3
|
465cm3
|
670cm3
|
871cm3
|
949m3
|
1000m3
|
|
5
|
Connections
|
G3/8"
|
G3/8"
|
G 1/2"
|
G 1/2"
|
G 1/2"
|
G 1/2"
|
|
6
|
Max axial load(static)
|
30kN
|
55kN
|
60kN
|
100kN
|
120kN
|
160kN
|
|
7
|
Max axial load(dynamic)
|
15kN
|
25kN
|
30kN
|
50kN
|
60kN
|
60kN
|
|
8
|
Weight
|
23kg
|
35kg
|
52kg
|
64kg
|
76kg
|
82kg
|
Application
for timber crane
for tractor
for skid steer loader
for loaders
for bell logger
for mini excavator
Production
T36 rotator log grapple production in our workshop ( for USA, CHILE, market)
Packing
More Grapples
Pins on bracket log grapple
Rotating log grapple
Manual log grapple
HOMIE
H
OMIE Focus on Excavator Attachments products design and making!
Our main products
:
Grapples, Pulverizers, Crushers, Hydraulic Shears, Screening Bucket, Crusher Buckets, Tilt Quick Hitches.
Main export market:
USA, JAPAN, KOREA, GREECE, AUSTRIA,ITALY,SPAIN.
1.Over 10 years attachments production experience
2. 10 persons technical team
3. 60 persons production team
4. over 5000 sets productivity per year
