Quick Details
-
Panel Size:
-
46" 49" 55" 65"
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
ZX-VD55
-
Pixel Pitch:
-
0.63mm
-
Panel Type:
-
DID LCD screen & LED light
-
Brand (Option):
-
LG/Samsung/Innolux/AUO/BOE etc.
-
Resolution:
-
1920x1080(FHD)
-
Brightness:
-
500nits, 700nits
-
View Angle (H / V):
-
178°/178°
-
Active Area (mm):
-
1209.6x680.4mm
-
Aspect ratio:
-
16:9
-
Warranty:
-
12 Months
-
Screen Dimension:
-
1211.4x682.2x108mm
-
Feature:
-
Intelligent Split Screen
Quick Details
-
Application:
-
Indoor
-
Brand Name:
-
Zhongxin
-
Color:
-
Black
-
Panel Size:
-
46" 49" 55" 65"
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
ZX-VD55
-
Pixel Pitch:
-
0.63mm
-
Panel Type:
-
DID LCD screen & LED light
-
Brand (Option):
-
LG/Samsung/Innolux/AUO/BOE etc.
-
Resolution:
-
1920x1080(FHD)
-
Brightness:
-
500nits, 700nits
-
View Angle (H / V):
-
178°/178°
-
Active Area (mm):
-
1209.6x680.4mm
-
Aspect ratio:
-
16:9
-
Warranty:
-
12 Months
-
Screen Dimension:
-
1211.4x682.2x108mm
-
Feature:
-
Intelligent Split Screen
Products Description
|
PANEL PARAMETER
|
|
|
|
|
||||
|
Screen size
|
55 inch
|
65 inch
|
49inch
|
46 inch
|
||||
|
Screen type
|
LCD Screen with LED back light
|
|
|
|
||||
|
LCD Brand
|
LG/Samsung/BOE
|
|
|
|
||||
|
Super Narrow Bezel
|
3.5mm
|
3.5mm
|
3.5mm
|
3.5mm
|
||||
|
Resolution FHD
|
1920 x 1080P
|
3840 x 2160P
|
1920 x 1080P
|
1920 x 1080P
|
||||
|
Brightness
|
500cd/m2
|
500cd/m2
|
500cd/m2
|
500cd/m2
|
||||
|
Display Area(H/V)mm
|
1209.6 x 680.4
|
1428.48 x 803.52
|
1073.8×604
|
1018.08×572.67
|
||||
|
Dot Pitch(H/V)mm
|
0.630 × 0.630
|
0.372×0.372
|
0.5593x0.5593
|
0.53025x0.53025
|
||||
|
Contrast Ratio
|
1200-3000 : 1
|
1200-3000 : 1
|
1200-3000 : 1
|
1200-3000 : 1
|
||||
|
Display Colour
|
6:7M(8bit)
|
|
|
|
||||
|
View Angle (H/V)
|
178°/178°
|
|
|
|
||||
|
Response Time
|
<=6ms
|
|
|
|
||||
|
|
|
|
|
|
||||
|
Aspect ratio
|
|
16:9
|
|
|
||||
|
Quality compensation technology
|
|
LTI,CTI
|
|
|
||||
|
Motion compensation technolog
|
|
AUTO MOVE
|
|
|
||||
|
Filter
|
|
3D comb filtering, digital noise reduction
|
|
|
||||
|
Video starnar
|
|
PAL,NTSC
|
|
|
||||
|
Video Wall Controller(Built-in each Screen)
|
|
|
|
|
||||
|
Digital signal input
|
|
HDMI×1； 1920x1080@60Hz backward compatible
|
|
|
||||
|
Computer signal input
|
|
VGA(DB-15) ×1；1920x1080@60Hz backward compatible
|
|
|
||||
|
Digital signal input
|
|
DVI(DVI-I)×1；1080P(1920×1080) backward compatible
|
|
|
||||
|
Composite Video Input/(AV)
|
|
CVBS(BNC)x1
|
|
|
||||
|
Composite Video Output
|
|
CVBS(BNC)x1
|
|
|
||||
|
RJ45
|
|
4
|
|
|
||||
|
USB
|
|
1(optional)
|
|
|
||||
|
Computer centralized control interface
|
|
RS232
|
|
|
||||
|
OTHERS
|
|
|
|
|
||||
|
Shell material
|
|
Metal shell
|
|
|
||||
|
Installation way
|
|
Wall mount, floor standing mount,hanging mount
|
|
|
||||
|
Power Supply
|
|
AC100V～240
|
|
|
||||
|
Power Consumption (Max)
|
|
240W
|
|
|
||||
|
Standby Power Consumption
|
|
<=3
|
|
|
||||
|
Working Temperature
|
|
0°C~50°C
|
|
|
||||
|
Working Humidity
|
|
20% - 80%
|
|
|
||||
|
Storage Temperature
|
|
-20°C - 60°C
|
|
|
||||
