JGS-1B Intelligent Engineering Well Logging System is used to measure various parameters of water well, oil well, coal well.

JGS-1B Intelligent Engineering  Well Logging System

Main Applications and Features

1 Coal Field Digital Integrated Logging

2 Hydrological Engineering Digital Integrated Logging

3 Solid Metal Ore Digital Integrated Logging

4 Other Minerals Digital Integrated Logging

5 External Laptop (Desktop PC)

6 For upward logging, also for downward logging

7 Receive digital signal, analog signal

8 8 taps of power supply current, Optional

9 Automatic sampling as per depth interval, sampling interval arbitrarily

10 Indoor simulation logging, repeatability observation of instruments and probes

11 Membrane panel, attractive and durable

Technical Specifications

1 12bit A/D Conversion, Program-Controlled Magnification K=0.5~128

2 Counting Channel: f≤500KHz

3 Digital Signal Transmission Frequency: 9600bit/s

4 Power Supply Cycle: 400ms

5 Current: 2mA~500 mA Optional

6 Signal Input Range: ≤±10V

7 Continuous Working Time: ≤24 hr

8 Power Consumption: <200W

9 Volume: 420×260×210mm,

10 Weight: <7Kg

11 Working Temperature Range: -10°C~ +50°C

12 Working Power Supply: AC220V±10% 50Hz ±5%

13 Logging Speed: 0~30 m/min Adjustable (as per sampling interval)

Logging Working Software System

1 12bit A/D Conversion, Program-Controlled Magnification

2 ?Operation Environment: Windows98/2000/XP

3 Sampling Interval: Arbitrary (1~1000cm)
Setting (1cm, 2cm, ...1000cm)

4 Maximum depth of one-time acquisition: 3000m (0.1m sampling interval)

5 Depth automatic alignment of multi-parameters

6 Superposition of multi-parameters up to 10

7 Curve movement, anomaly removal, smoothing, inverted order, , segmentation, calculation, etc.

8 Interpretation of profile input, automatic generation of rock stratum name, thickness and baseplate depth

9 Curve amplification and compression

10 5 types of curve depth ratio: 1:50, 1:100, 1:200, 1:500, 1:1000

11 Continuous drawing production in color or black-and-white effects

12 Output graph maximum width: 415mm, length: 2310mm
