Quick Details
-
Application:
-
roof waterproofing, Pond liner, waterproof materials, roofing waterproof sheet.
-
Design Style:
-
Contemporary
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
BP
-
Model Number:
-
BP-1
-
Type:
-
EPDM, Homogeneous or EPDM with fabric backing , self adhesive EPDM membrane
-
Product Name:
-
EPDM rubber membrane for roofing
-
Material:
-
EPDM
-
Color:
-
black, white
-
Thickness:
-
0.6mm to 2mm
-
Roll Length:
-
20-200m/roll, as your request.
-
Roll Width:
-
1-2m,4-8m, as your request.
-
standards:
-
USA ASTM/GRI-GM13 or China GB, as your request
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
Online technical support
-
Application:
-
roof waterproofing, Pond liner, waterproof materials, roofing waterproof sheet.
-
Design Style:
-
Contemporary
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
BP
-
Model Number:
-
BP-1
-
Type:
-
EPDM, Homogeneous or EPDM with fabric backing , self adhesive EPDM membrane
-
Product Name:
-
EPDM rubber membrane for roofing
-
Material:
-
EPDM
-
Color:
-
black, white
-
Thickness:
-
0.6mm to 2mm
-
Roll Length:
-
20-200m/roll, as your request.
-
Roll Width:
-
1-2m,4-8m, as your request.
-
standards:
-
USA ASTM/GRI-GM13 or China GB, as your request
Products Description
EPDM Membrane is made of ethylene-propylene ternary rubber mixed with butyl rubber, curing agent, accelerant, softener and reinforcing agent, which is processed by mixing, drawing filter, extrusion molding and so on. Because there are no double bonds in the main chain of ethylene propylene ternary rubber, so when it is affected by ozone, ultraviolet ray and wet heat, it is not easy to break on the main bond, so it has excellent weather resistance and aging resistance. Moreover, high tensile strength, large elongation rate, strong adaptability to base course expansion or cracking, light weight, wide range of service temperature (can be used for a long time in the range of-40 ~ 80 ºC), is a kind of high efficiency. It can also cold construction, simple operation,reduce environmental pollution, improve workers' working conditions.
Product Property
1.Excellent anti-aging, long service life about 50years.
2.High elongation, tensile strength, little dimensional changes after heat treatment.
3.Excellent resistance to root puncture, can be used as waterproof layer of green roof.
4.Good flexibility at low temperature, great ability to adapt to the environment changes.
5.Excellent resistance to ozone and UV light, chemical attack, can be applicable to the special environment.
6.Easy to repair, low cost.
7.Excellent resistance to hole-punching.
2.High elongation, tensile strength, little dimensional changes after heat treatment.
3.Excellent resistance to root puncture, can be used as waterproof layer of green roof.
4.Good flexibility at low temperature, great ability to adapt to the environment changes.
5.Excellent resistance to ozone and UV light, chemical attack, can be applicable to the special environment.
6.Easy to repair, low cost.
7.Excellent resistance to hole-punching.
Product Paramenters
|
PRODUCT NAME
|
EPDM waterproof membrane
|
|
Thickness
|
0.6mm to 2mm
|
|
Roll Width
|
1-2m,4-8m, as your request.
|
|
Roll Length
|
20-200m/roll, as your request
|
|
Color
|
black, white
|
|
The item name
|
|
|
Indication
|
|
Applicable test items
|
|||
|
Tension Strength （MPa）
|
|
Normal temperature≥
|
7.5
|
|
GB6.3.2
|
|||
|
|
|
60℃≥
|
2.3
|
|
|
|||
|
Elongation at break %
|
|
Normal temperature≥
|
450
|
|
|
|||
|
|
|
－20℃
|
200
|
|
|
|||
|
Tear strength N
|
|
≥
|
25
|
|
GB6.3.3
|
|||
|
（0.3Mpa.30 min）Water tightness
|
|
|
No seeage
|
|
GB6.3.4
|
|||
|
Flexibility at low temperature （℃）≤
|
|
|
－40
|
|
GB6.3.5
|
|||
|
Heat expansion (mm)
|
Extended ≤
|
|
|
2
|
GB6.3.6
|
|||
|
|
Contraction ≤
|
|
|
4
|
|
|||
|
（80℃×168h）
Hot air ageing |
Fracture tensile strength retention %≥
|
|
|
80
|
GB6.3.7
|
|||
|
|
Keep rate tore elongation%≥
|
|
|
70
|
|
|||
|
Alkaline
［10%Ca(OH)2 Normal temperature×168h] |
Fracture tensile strength retention %≥
|
|
|
80
|
GB6.3.8
|
|||
|
|
Keep rate tore elongation%≥
|
|
|
80
|
|
|||
|
（40℃×168h）,200×10-8 Ozone aging
|
|
|
|
—
|
GB6.3.9
|
|||
|
Artificial climate ageing
|
|
Fracture tensile strength retention %≥
|
|
80
|
GB6.3.10
|
|||
|
|
|
Tear elongation retention rate %≥
|
|
70
|
|
|||
|
Bond peel strength(sheet and sheet)
|
|
N/mm Standard test condition ≥
|
|
1.5
|
GB6.3.11
|
|||
|
|
|
Immersion retention rate（Normal temperature×168h） %≥
|
|
70
|
|
|||
Applications
Pond liner, waterproof materials, roofing waterproof sheet.
