Quick Details
-
Model Number:
-
STX812M
-
Shell Material:
-
plywood
-
The body material:
-
plywood
-
System type:
-
12" stage monitor
-
Frequency response:
-
75 Hz-20 kHz
-
Power handling:
-
450W/900W/1800W
-
Components:
-
Super ferrite magnet drivers
-
Maximum SPL:
-
130dB SPL Peak
-
Nominal Impedance:
-
8 ohms
-
Enclosure:
-
CNC-machined 18mm birch plywood
-
Paint:
-
Polyurea paint
-
Recommended amplifier:
-
650W
-
Input Connector:
-
2X NL4 speakon
Quick Details
-
Warranty:
-
3months-1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SKYTONE
-
Model Number:
-
STX812M
-
Shell Material:
-
plywood
-
The body material:
-
plywood
-
System type:
-
12" stage monitor
-
Frequency response:
-
75 Hz-20 kHz
-
Power handling:
-
450W/900W/1800W
-
Components:
-
Super ferrite magnet drivers
-
Maximum SPL:
-
130dB SPL Peak
-
Nominal Impedance:
-
8 ohms
-
Enclosure:
-
CNC-machined 18mm birch plywood
-
Paint:
-
Polyurea paint
-
Recommended amplifier:
-
650W
-
Input Connector:
-
2X NL4 speakon
Why choose skytone audio?
1. Quality is our culture.
2. With us your money in safe, your business in safe.
3. Providing with exceptional service, saving your time and money.
4. One of market leader for audio business since 2004.
5. Direct factory provides you factory price, no middle man.
STX812M 12 inch speaker box empty speaker cabinets
Stage monitor
Monitor speakers
Professional speaker
Speaker box
Pa system
1. in pro audio business SINCE 2004, with the excellent before or after-sales servive.
2. Professional research department and engineer assured the super quality
3. Installed super ferrite magnet speakers inside
4. Bi-amp is available
5. Imported polyurea paint, which is Anti-corrosive, waterproof, scratch-resistant, environmental without bad smell.
Overview:
Designed specifically to be a high performance 12" two-way floor monitor, it can also do double duty as a utility speaker for use on a tripod stand or over a subwoofer, utilizing a single-position pole mount
Features:
1. Compact and low-profile for minimal obstruction of audience sight-lines.
2. 70° X 70° Nominal coverage.
3. Bi-amplified or full-range passive operation.
4. Pole socket for applications requiring pole or tripod mounting.
5. High power handling, low distortion Super ferrite magnet LF driver.
6. Super compression driver.
7. Imported polyurea paint
8. 14-Gauge steel grille lined with acoustically transparent cloth.
Specifications:
| Model | STX812M |
| System type | 2 way 1X12" stage monitor |
| Frequency Range ( –10 dB) | 50 Hz-20 kHz |
| Frequency Response (± 3 dB) | 75 Hz-20 kHz |
| Coverage Pattern | 70× 70 nominal |
| Sensitivity (1W/1m) | 95 dB |
| Power Rating | 450 W / 900 W / 1800 W |
| (Continuous/Program/Peak) | |
| Rated Maximum SPL | 130 dB SPL Peak |
| Nominal Impedance | 8Ω |
| Input Connectors | Two NL4 Speakon |
| Operational Modes | Full Range/Bi-Amp |
| Paint | Imported polyurea paint |
| Cabinet | 18mm birch plywood |
| Recommend amplifier | I--tech 5000 (2X650Watts) Digital amplifier |
| Warranty | 1 year (Non-artificial damage) |
| Dimensions (H x W x D) | 571 mm x 355 mm x 264 mm |
| Net Weight | 19 kg |
Application
1. Live performance stage monitoring
2. Speech reinforcement
3. Reinforcement of vocal and acoustic music
4. High-performance satellite speaker for use with subwoofers
Product details:
1. CNC-machined, birch plywood cabinet, 18mm,13-ply
2. Imported polyurea paint, which is Anticorrosive, waterproof, scratch-resistant, environmental without bad smell.
3. Inside components
4. Bi-amp or Full range operation
5. Support on tripod or subwoofer, 35mm pole socket
Performance show:
Customer feedback:
Shipping and delivery:
1. Fedex/DHL/UPS/TNT/ for samples, door to door
2. By air or by sea for batch goods, for FCL; Airport / port receiving
3. Customers specifiying freight forwarders or negotiables shipping methods!
Delivery time:
1-2 days for samples;
7-10 days for batch goods.
