Quick Details
-
Use:
-
Warehouse Rack
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
E-deck
-
Model Number:
-
EDN1302
-
Weight Capacity:
-
1000 kg
-
Width:
-
1200 mm
-
Height:
-
1200 mm
-
Product name:
-
Pallet frame nestainer stacking rack for storage system
-
External Size:
-
1300LX1200W X1200H(mm)
-
Quantity/40HQ:
-
160 Sets
-
Nestainer Racks stackability:
-
6-8 high
-
Finish:
-
Colorful powder coating
-
Application:
-
Widely used in warehouse,logistic
-
Function:
-
Large Load Capacity Warehouse Storage
-
Product shelf life:
-
Up to 3 to 5 years against proper handling
-
Remark:
-
Customized & OEM support
Quick Details
-
Type:
-
Pallet Rack
-
Material:
-
Steel
-
Feature:
-
Corrosion Protection
-
Use:
-
Warehouse Rack
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
E-deck
-
Model Number:
-
EDN1302
-
Weight Capacity:
-
1000 kg
-
Width:
-
1200 mm
-
Height:
-
1200 mm
-
Product name:
-
Pallet frame nestainer stacking rack for storage system
-
External Size:
-
1300LX1200W X1200H(mm)
-
Quantity/40HQ:
-
160 Sets
-
Nestainer Racks stackability:
-
6-8 high
-
Finish:
-
Colorful powder coating
-
Application:
-
Widely used in warehouse,logistic
-
Function:
-
Large Load Capacity Warehouse Storage
-
Product shelf life:
-
Up to 3 to 5 years against proper handling
-
Remark:
-
Customized & OEM support
Hot sale safe stackable transportation malaysia pallet frame nestainer stacking rack for storage system
Exclusive Inverted Angles--Safe, secure and simple stacking
Specifications of metal steel stacking nestainer
| Model No. | Exterior Dimension | Interior Dimension |
Loading capacity |
Stackability |
Total container |
| LxWxH(mm) | LxWxH(mm) | kg | |||
| EDN1302 | 1300x1200x1200 | 1200x1150x1000 | 1000 | 4 | 1x40'HQ |
| EDN1304 | 1300x1200x1400 | 1200x1150x1200 | 1000 | 4 | |
| EDN1402 | 1400x1200x1200 | 1300x1150x1000 | 1000 | 4 | 1x40'HQ |
| EDN1404 | 1400x1200x1400 | 1300x1150x1200 | 1000 | 4 | |
| EDN1502 | 1500x1200x1200 | 1400x1150x1000 | 1000 | 4 | 1x40'HQ |
| EDN1504 | 1500x1200x1400 | 1400x1150x1200 | 1000 | 4 | |
| EDN1602 | 1600x1200x1200 | 1500x1150x1000 | 1000 | 4 | 1x40'HQ |
| EDN1604 | 1600x1200x1400 | 1500x1150x1200 | 1000 | 4 | |
| Material | Mild steel Q235 | ||||
| Finish | Powder coating | ||||
| Available design | Detachable/undetachable | ||||
| Application area | Warehouse, logistic, recycling, etc. | ||||
| Remark | Costomized or OEM support | ||||
| Key features |
1. Safe, secure and simple stacking 2. Increased handling and storage flexibility 3. By positioning the bottom angles of the top rack over the stacking tubes of the unit below, the Nestainer rack can be guided into it’s stacked position for full column-to-column loading |
||||
