Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HK
-
Model Number:
-
DS-2CE10DF8T-F
-
Image Sensor:
-
2 MP CMOS
-
Signal System:
-
PAL/NTSC
-
Lens:
-
2.8 mm, 3.6 mm, 6 mm Fixed Lens
-
Resolution:
-
1920 (H) * 1080 (V)
-
Day & Night:
-
Color
-
WDR (Wide Dynamic Range):
-
≥130 dB
-
White Balance:
-
Auto
-
Video Output:
-
Switchable TVI/AHD/CVI/CVBS
-
Protection Level:
-
IP68
-
White Light Range:
-
Up to 20 m
Quick Details
-
Special Features:
-
NIGHT VISION, Vandal-proof, Waterproof / Weatherproof, One-way Audio, Low Power, COLOR VU
-
Function:
-
Built-in Mic, NIGHT VISION, Waterproof / Weatherproof, One-way Audio, Vandal-proof, COLOR VU
-
Customized support:
-
Online technical support, Customized logo, OEM, ODM
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HK
-
Model Number:
-
DS-2CE10DF8T-F
-
Image Sensor:
-
2 MP CMOS
-
Signal System:
-
PAL/NTSC
-
Lens:
-
2.8 mm, 3.6 mm, 6 mm Fixed Lens
-
Resolution:
-
1920 (H) * 1080 (V)
-
Day & Night:
-
Color
-
WDR (Wide Dynamic Range):
-
≥130 dB
-
White Balance:
-
Auto
-
Video Output:
-
Switchable TVI/AHD/CVI/CVBS
-
Protection Level:
-
IP68
-
White Light Range:
-
Up to 20 m
Key Features
Features
High quality imaging with 2 MP, 1920 × 1080 resolution
24/7 color imaging
Clear imaging against strong back light due to 130 dB true WDR technology
3D DNR technology delivers clean and sharp images
2.8 mm, 3.6 mm, 6 mm fixed focal lens
Up to 20 m white light distance for bright night imaging
One port for four switchable signals (TVI/AHD/CVI/CVBS)
Water and dust resistant (IP68)
Product spec
|
Camera
|
|
|
|
Image Sensor
|
2 MP CMOS
|
|
|
Signal System
|
PAL/NTSC
|
|
|
Resolution
|
1920 (H) × 1080 (V)
|
|
|
Frame Rate
|
TVI: 1080p@25fps/30fps
CVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVBS: PAL/NTSC |
|
|
Min. Illumination
|
0.0003 Lux @ (F1.0, AGC ON), 0 Lux with white light ON
|
|
|
Shutter Time
|
PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
|
|
|
Slow Shutter
|
Max. 16 times
|
|
|
Lens
|
2.8 mm, 3.6 mm, 6 mm Fixed Lens
|
|
|
Field of View
|
2.8 mm, horizontal FOV: 106°, vertical FOV: 56°, diagonal FOV: 129°
3.6 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 100° 6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 64° |
|
|
Lens Mount
|
M12
|
|
|
Light Alarm
|
Solid Light Alarm (White Light)
|
|
|
Day & Night
|
Color
|
|
|
WDR (Wide Dynamic Range)
|
≥130 dB
|
|
|
Angle Adjustment
|
Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
|
|
|
Menu
|
|
|
|
White Light
|
Auto/Off
|
|
|
Image Mode
|
STD/HIGH-SAT/HIGHLIGHT
|
|
|
AGC
|
Yes
|
|
|
Day/Night Mode
|
Color
|
|
|
White Balance
|
Auto
|
|
|
AE (Auto Exposure) Mode
|
WDR, BLC, HLC, Global, HLS
|
|
|
Privacy Mask
|
4 programmable privacy masks
|
|
|
Motion Detection
|
4 programmable motion areas
|
|
|
Noise Reduction
|
3D DNR/2D DNR
|
|
|
Language
|
English
|
|
|
Function
|
Brightness, Contrast, Mirror, Sharpness, Anti-Banding, Smart Light
|
|
|
Interface
|
|
|
|
Video Output
|
Switchable TVI/AHD/CVI/CVBS
|
|
|
General
|
|
|
|
Operating Conditions
|
-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
|
|
|
Power Supply
|
12 VDC ± 25%,
*You are recommended to use one power adapter to supply the power for one camera. |
|
|
Consumption
|
Max. 3.1 W
|
|
|
Protection Level
|
IP68
|
|
|
Material
|
Metal
|
|
|
White Light Range
|
Up to 20 m
|
|
|
Communication
|
HIKVISION-C
|
|
|
Dimension
|
161.1 mm × 70 mm × 70 mm (6.34" × 2.76" × 2.76")
|
|
|
Weight
|
Approx. 390 g (0.86 lb.)
|
|
