Quick Details
-
External dimensions:
-
1400*190*980 (mm)
-
Case material:
-
domestic standard 304 stainless steel
-
Working voltage:
-
AC220 ± 10% V/50HZ 100W
-
Fire linkage function:
-
infrared 3 pairs
-
Drive motor:
-
24V DC brushless motor
-
Telescopic arm length:
-
250mm
-
Travel direction:
-
one-way or two-way (can be set)
-
Traffic speed:
-
40 people/minute (normally open)
-
Normal service life:
-
over 5 million times
Quick Details
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Rige
-
Model Number:
-
06-02
-
External dimensions:
-
1400*190*980 (mm)
-
Case material:
-
domestic standard 304 stainless steel
-
Working voltage:
-
AC220 ± 10% V/50HZ 100W
-
Fire linkage function:
-
infrared 3 pairs
-
Drive motor:
-
24V DC brushless motor
-
Telescopic arm length:
-
250mm
-
Travel direction:
-
one-way or two-way (can be set)
-
Traffic speed:
-
40 people/minute (normally open)
-
Normal service life:
-
over 5 million times
Product Description
Case
Specification
|
item
|
value
|
|
Place of Origin
|
China
|
|
Size parameters
|
1400 * 190 * 980mm Custom
|
|
Case material
|
domestic standard 304 stainless steel, case thickness 1.2mm
|
|
Working voltage
|
AC220 ± 10% V/50HZ 100W
|
|
Fire linkage function
|
infrared 3 pairs
|
|
Travel direction
|
one-way or two-way (can be set)
|
|
Telescopic arm length
|
250mm
|
|
Traffic speed
|
40 people/minute (normally open)
|
|
Drive motor
|
24V DC brushless motor
|
|
Working environment
|
indoor and outdoor (shaded) -25 ℃~70 ℃ Relative humidity: ≤ 90%, non condensing
|
|
Barrier materials
|
PU soft baffle and plastic acrylic baffle (optional)
|
|
Normal service life
|
over 5 million times
|
|
Communication interface
|
Standard RS485 interface, distance ≤ 1200 meters
|
|
Input interface
|
Relay switch signal or 12V level signal or 12V pulse signal with a pulse width greater than 100ms, driving current greater than 10Ma
|
