Quick Details
-
Brand Name:
-
hwashen
-
Model Number:
-
HS
-
Input frequency:
-
2150~2686MHz
-
Gain stability over temp:
-
±2dB
-
LO leakage IF port:
-
<-45dBm
-
LO phase noise:
-
-92dBc@10kHz-99dBc@100kHz
-
Image rejection:
-
>80dB
-
Supply voltage:
-
+15 VDC to +24 VDC
-
Temperature:
-
-40 to +70°C
-
Output impedance:
-
75 ohms
-
VSWR:
-
1.5:1
-
High Definition:
-
Yes
Quick Details
-
Type:
-
Outdoor
-
Frequency Range:
-
2150~2686MHz
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
hwashen
-
Model Number:
-
HS
-
Input frequency:
-
2150~2686MHz
-
Gain stability over temp:
-
±2dB
-
LO leakage IF port:
-
<-45dBm
-
LO phase noise:
-
-92dBc@10kHz-99dBc@100kHz
-
Image rejection:
-
>80dB
-
Supply voltage:
-
+15 VDC to +24 VDC
-
Temperature:
-
-40 to +70°C
-
Output impedance:
-
75 ohms
-
VSWR:
-
1.5:1
-
High Definition:
-
Yes
|
ITEM |
Product parameter |
|
Gain options |
55dB/60dB/65dB or as per requests |
|
|
Input frequency |
2150-2162MHz / 2500~2686MHz |
|
|
Output frequency |
116-128MHz / 222 - 408MHz |
|
|
Gain stability over temp |
± 2dB |
|
|
Noise figure |
2.5dB± 0.5dB |
|
|
VSWR |
1.5:1 |
|
|
LO frequency |
1,838MHz, 1,950MHz, 2278MHz or as per requests |
|
|
LO frequency stability |
± 25kHz over temp |
|
|
LO phase noise |
-92dBc@10kHz -99dBc@100kHz |
|
|
LO leakage IF port |
<-45dBm |
|
|
LO leakage antenna port |
<-60dBm |
|
|
Image rejection |
>80dB |
|
|
IF rejection |
>80dB |
|
|
Output impedance |
75 ohms |
|
|
Supply voltage |
+15 VDC to +24 VDC |
|
|
Temperature |
-40 to +70° C |
Product advantage
1)
Good reception
2) 100% weatherproof
3) PCS/WCS rejection
Danyang Remote Control Antenna Factory
has been engaged in the production of electric appliances since 1987. We produce TV antennas, DVB-T/T2 antennas, satellite receivers, coaxial cables, and related accessories. Having been in this industry for over 20 years, we have 20,000 square meter factory workshop, a dedicated team of professionals, 3 branch offices, and one subsidiary joint venture company. In addition, we have advanced production equipment imported from America and Japan from such leading companies as NEC, HP, Motorola and so on. Placing much emphasis on providing quality products, our company put in place a stringent quality control system and has received ISO9001 certification. As a result, we currently export over 99% of our production and enjoy upstanding reputation. Our major markets include the UAE, Africa, America, European, Asia, and Brazil. Our pursuit of first-rate quality, reasonable prices and comprehensive after sales services offers both potential and long-standing clientele confidence in our company. If you requires any of our product , please feel free to contact us.
Q:Are you a manufacturer or a trading company?
A: We have been professional antenna manufacturer for 20 years.
Q: What's your company MOQ?
A: our company don't have MOQ. We also accept small quantity.
Q: Can your company accept customize?
A: Welcome OEM & ODM.
Q: What's your delivery time?
A:If our company have stock ,will send to you within one day once receive your deposit.
If use customer brands, we will take a 5-10 working days to prepare materials and mass production.
Q: Can you send a sample for us to test ?
A: Yes, we can. Sample can send out once you ask for it, if the samples cost is very higher ,we will ask a sample fee. At the same time . the Sample fee will return back in future order. If the samples cost is lower, we can send to you free , but you also take the shipping cost
.
