Quick Details
-
Front Suspension:
-
Double A-arm870mm
-
Rear Suspension:
-
Swingarm 1000mm
-
Max. loading:
-
280KG
-
Starting:
-
Electric start
Quick Details
-
Material:
-
steel
-
Brand Name:
-
DW
-
Place of Origin:
-
Shandong, China
-
Front Suspension:
-
Double A-arm870mm
-
Rear Suspension:
-
Swingarm 1000mm
-
Max. loading:
-
280KG
-
Starting:
-
Electric start
Product Description
Specification
|
200CC ATV
|
|
|
|
|
||||
|
Loading Infomation
|
|
|
|
|
||||
|
40ft HQ Container
|
|
42 Units
|
|
|
||||
|
20ft HQ Container
|
|
12 Units
|
|
|
||||
|
Packing Size
|
|
1800*1070*1070mm
|
|
|
||||
|
Net weight
|
|
190 KGS
|
|
|
||||
|
Gross Weight
|
|
216 KGS
|
|
|
||||
|
Engine & Drivetrain
|
|
|
|
|
||||
|
Engine Type
|
|
180CC engine, Air cooled,4 strokes, single sylinder
|
|
|
||||
|
Compression Ratio
|
|
10:01
|
|
|
||||
|
Transmission
|
|
F-N-R
|
|
|
||||
|
Max. power
|
|
9Kw/8000r/min
|
|
|
||||
|
Max. torque
|
|
13N.m/6000r/min
|
|
|
||||
|
Suspension and brake
|
|
|
|
|
||||
|
Front/Rear Suspension
|
|
Double A-arm 870mm/Swing arm 1000mm
|
|
|
||||
|
Front/Rear brake
|
|
Disc brake/Single hydraulic disc brake
|
|
|
||||
|
Tires/Wheels
|
|
|
|
|
||||
|
Wheels
|
|
Aluminum(10 inch)
|
|
|
||||
|
Front/Rear wheels
|
|
23x7-10/22x10-10
|
|
|
||||
|
Other features
|
|
|
|
|
||||
|
Seat height
|
|
500mm
|
|
|
||||
|
Fuel capacity
|
|
8.5L
|
|
|
||||
|
Max. loading
|
|
280KG
|
|
|
||||
|
Max. speed
|
|
60km/h
|
|
|
||||
|
Starting
|
|
Electric start
|
|
|
||||
|
Ignition
|
|
CDI
|
|
|
||||
|
Battery
|
|
9Ah, 12V water-battery
|
|
|
||||
|
300CC ATV
|
|
|
|
|
||||
|
Loading Infomation
|
|
|
|
|
||||
|
40ft HQ Container
|
|
36 Units
|
|
|
||||
|
20ft HQ Container
|
|
12 Units
|
|
|
||||
|
Packing Size
|
|
1970*1140*850mm
|
|
|
||||
|
Gross Weight
|
|
310 kg
|
|
|
||||
|
Engine & Drivetrain
|
|
|
|
|
||||
|
Engine Type
|
|
300cc engine,Water Cooled
|
|
|
||||
|
Compression Ratio
|
|
10.5 : 1
|
|
|
||||
|
Drive System
|
|
Chain Drive 530H
|
|
|
||||
|
Max Power
|
|
13.5kw/7000rpm
|
|
|
||||
|
Max Torque
|
|
20.5N.m/5200rpm
|
|
|
||||
|
Transmission
|
|
CVT F-N-R
|
|
|
||||
|
Starting system
|
|
Electric start
|
|
|
||||
|
Brakes
|
|
|
|
|
||||
|
Front/Rear Barkes
|
|
4-Wheel Hydraulic Disc
|
|
|
||||
|
Additional Spesifications
|
|
|
|
|
||||
|
Lighting
|
|
Full LED lights
|
|
|
||||
|
Mirrors
|
|
Rear mirror
|
|
|
||||
|
Speedometer
|
|
TFT
|
|
|
||||
|
Tires/Wheels
|
|
|
|
|
||||
|
Wheels
|
|
Cast Aluminum
|
|
|
||||
|
Front/Rear Tires
|
|
25×8-12/25×10-12
|
|
|
||||
|
Suspension
|
|
|
|
|
||||
|
Front/Rear Suspension
|
|
Dual A-arm/Swing Arm
|
|
|
||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
