Quick Details
-
Place of Origin:
-
Haryana, India
-
Brand Name:
-
MARS
-
Model Number:
-
Mars -13
-
Material:
-
Stainless Steel, Metal, Plastics
-
Dimension:
-
3 Step
-
Magnification:
-
5X10X20, 20X
-
Product name:
-
Operation Microscope
-
Application:
-
Hospital
-
Illumination:
-
LED Illumination
-
Eyepiece:
-
12.5x WF
-
Focusing:
-
Manual Focus
-
Feature:
-
High Resolution
-
Usage:
-
Iris Observation
-
Color:
-
White+ Black
-
Type:
-
Table Clamp
Quick Details
-
Warranty:
-
1 Year
-
Theory:
-
Ophthalmic Microscope
-
Drawtube:
-
BINOCULAR
-
Place of Origin:
-
Haryana, India
-
Brand Name:
-
MARS
-
Model Number:
-
Mars -13
-
Material:
-
Stainless Steel, Metal, Plastics
-
Dimension:
-
3 Step
-
Magnification:
-
5X10X20, 20X
-
Product name:
-
Operation Microscope
-
Application:
-
Hospital
-
Illumination:
-
LED Illumination
-
Eyepiece:
-
12.5x WF
-
Focusing:
-
Manual Focus
-
Feature:
-
High Resolution
-
Usage:
-
Iris Observation
-
Color:
-
White+ Black
-
Type:
-
Table Clamp
Product Description
Specification
|
item
|
value
|
|
Warranty
|
1 Year
|
|
Customized support
|
ISO, OEM
|
|
Place of Origin
|
India
|
|
|
Haryana
|
|
Brand Name
|
MARS
|
|
Model Number
|
Mars -13
|
|
Theory
|
Ophthalmic Microscope
|
|
Drawtube
|
Binocular
|
|
Material
|
Stainless Steel, Metal, Plastics
|
|
Dimension
|
3 Step
|
|
Magnification
|
5X10X20
|
|
Product name
|
Ophthalmic Microscope
|
|
Application
|
Hospital
|
|
Eyepiece
|
12.5 X wide field high eye point
|
|
Interpupil Adjustment
|
50 mm to Dia 75 mm.
|
|
Illumination Light Source
|
Cold light through, Fiber - Optic light guide
|
|
Illumination Light Intensity
|
1,00,000 Lux.
|
|
Stand Type
|
Table Mount
|
|
Feature
|
Easy To Installable
|
|
Weight
|
65kg Approx..
|
|
Color
|
White+ Black
|
TECHNICAL SPECIFICATION:-
Binocular Tube: 45 degree Inclined
Eye Pieces: 12.5x / 16mm Dioptric Adjustment
Magnification Changer: 3 step Magnification (5x, 15, 20x)
Objective: F= 175/200mm
Working Distance: 175/200mm
Interpupillary Distance: 55mm to 75mm
Adjustment Focusing System: Motorized Foot Focusing system.
Eye Pieces: 12.5x / 16mm Dioptric Adjustment
Magnification Changer: 3 step Magnification (5x, 15, 20x)
Objective: F= 175/200mm
Working Distance: 175/200mm
Interpupillary Distance: 55mm to 75mm
Adjustment Focusing System: Motorized Foot Focusing system.
ILLUMINATION SECTION
Type: By Optical Light Guide System
Light Source: 24V/250W Halogen Lamp OR LED
Illumination Control: Continuous Adjustment
Field of Illumination: 70mm
Filter: Cobalt Blue, Red-Free, Heat Absorbing Filter
Type: By Optical Light Guide System
Light Source: 24V/250W Halogen Lamp OR LED
Illumination Control: Continuous Adjustment
Field of Illumination: 70mm
Filter: Cobalt Blue, Red-Free, Heat Absorbing Filter
STAND SECTION
Type: Floor Stand, Table Clamp Or Wall Mounted
Vertical Range of Counter Balanced Arm: 400mm
GENERAL INFORMATION
Base Size: 600mm x 550mm
Weight: 50kg
Height: 1550mm
Electrical Power: AC 220V / 110V
Optional Accessories:
Type: Floor Stand, Table Clamp Or Wall Mounted
Vertical Range of Counter Balanced Arm: 400mm
GENERAL INFORMATION
Base Size: 600mm x 550mm
Weight: 50kg
Height: 1550mm
Electrical Power: AC 220V / 110V
* Beam Splitter assembly - easily installable
* T.V. relay lens System
* Monocular demonstration tube
* 1.5 x magnifying attachment for T.V. relay
* Stand - Table mounted
* Stand - Wall mounted
* Motorized fine focusing
