Quick Details
-
Model Number:
-
G1216-1RQ3AAU
-
Protection Level:
-
IP00 IP62 IP63
-
Operating Temperature:
-
-40℃ - +85℃
-
Max. Current:
-
0.25A 0.5A 16A 22A 26A
-
Lever type:
-
straight lever, Roller Lever, Ping Plunger,etc
-
Rating 1:
-
16A 125/250VAC 480VAC 1/8HP 125VAC 1/4HP 250VAC 0.5A 125VDC
-
Rating 2:
-
22A 125/250VAC 480VAC 1/4HP 125VAC 1/2HP 250VAC 0.25A 250VDC
-
Rating 3:
-
26A 125/250VAC 480VAC 1/2HP 125VAC 1HP 250VAC 0.5A 125VDC
-
Rating 4:
-
26A 125/250VAC u 40T85 5E4
-
Unit Net Weight:
-
Approx 60g
-
Terminal type:
-
screw terminal, Solder Terminals
-
Contact Resistance:
-
50mΩ Max.
-
Life electrical:
-
50,000 cycles; mechanical 10,000,000
-
Insulation Resistance:
-
100MΩ Min.
Quick Details
-
Max. Voltage:
-
125VDC 250VDC 125VAC 250VAC 277VAC 480VAC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Greetech
-
Model Number:
-
G1216-1RQ3AAU
-
Protection Level:
-
IP00 IP62 IP63
-
Operating Temperature:
-
-40℃ - +85℃
-
Max. Current:
-
0.25A 0.5A 16A 22A 26A
-
Lever type:
-
straight lever, Roller Lever, Ping Plunger,etc
-
Rating 1:
-
16A 125/250VAC 480VAC 1/8HP 125VAC 1/4HP 250VAC 0.5A 125VDC
-
Rating 2:
-
22A 125/250VAC 480VAC 1/4HP 125VAC 1/2HP 250VAC 0.25A 250VDC
-
Rating 3:
-
26A 125/250VAC 480VAC 1/2HP 125VAC 1HP 250VAC 0.5A 125VDC
-
Rating 4:
-
26A 125/250VAC u 40T85 5E4
-
Unit Net Weight:
-
Approx 60g
-
Terminal type:
-
screw terminal, Solder Terminals
-
Contact Resistance:
-
50mΩ Max.
-
Life electrical:
-
50,000 cycles; mechanical 10,000,000
-
Insulation Resistance:
-
100MΩ Min.
Huizhou Greetech Electronics Co., Ltd.: Manufacturer of '
Unionwell
', a high-tech enterprise, mainly engaged in R&D and production of various micro switches, automotive waterproof switches, various mechanical equipment switches, air pressure switches, mechanical keyboard switches, etc.The factory has passed ISO9001 and ISO/TS16949 quality assurance system, and has the world's various certification likes ENEC,CQC,CB LVD etc. Group procurement, business cooperation, brand joining, and ODM are welcome.
【Factory Direct Sale】【Integrity First】【Quality Assurance】
Welcome to visit the factory!
Remarks:
Various styles and configurations of micro switches have different prices, such as waterproof or dustproof, with or without wires, etc. Please contact our customer service for price negotiation or product online consultation!
Product Description
Specification
|
Rating
|
16A
|
ENEC/CQC
|
|
|
|
|
16A 125/250V or 480V 1/8HP 125VAC 1/4HP 250 VAC 0.5A 125VDC 0.25A 250VDC
|
|
|
|
|
16A 125/250VAC 5E4 u 40T85
|
|
|
|
22A
|
ENEC/CQC
|
|
|
|
|
22A 125/250V or 480V 1/4HP 125VAC 1/2HP 250 VAC 0.5A 125VDC 0.25A 250VDC
|
|
|
|
|
22A 125/250VAC 5E4 u 40T85
|
|
|
|
26A
|
ENEC/CQC
|
|
|
|
|
26A 125/250V or 480V 1/2HP 125VAC 1HP 250 VAC 0.5A 125VDC 0.25A 250VDC
|
|
|
|
|
26A 250VAC 5E4 u 40T85
|
|
|
|
Electrical
|
10-~30 cycles/minute
|
|
|
|
Mechanical
|
240 cycles/minute
|
|
|
Contact Resitance (Initial Value)
|
|
50mΩ Max
|
|
|
Insulation Resistance
|
|
100MΩ Min
|
|
|
( at 500VDC)
|
|
|
|
|
Dielectric Strength
|
between terminals
|
1500 VAC 50/60Hz 1min
|
|
|
|
between terminals and housing
|
2500 VAC 50/60Hz 1min
|
|
|
Storage Temperature
|
|
(-40℃~ + 85℃)
|
|
|
Storage Humidity
|
|
85% RH max
|
|
|
Service Life
|
Electrical
|
50,000~100,000cycles
|
|
|
|
|
(Depend on part number)
|
|
|
|
Mechanical
|
1,000,000cycles
|
|
|
Unit Net Weight
|
|
about 60g (Drip proof panel mounting type)
|
|
|
Trade Terms
|
|
1.The price is based on FOB Shenzhen or Hongkong or EXW factory
|
|
|
|
|
2.MOQ:5000pcs
|
|
|
|
|
Payment:T/T payment,50% deposit before production, balance 50% before shipment
|
|
|
Certificates
|
|
ISO9001&TS16949
|
|
|
|
|
RoHS & Reach
|
|
Related products
Packing & Delivery
1.pact out: 180pcs/CTN
2.Gross Weight: about 9KG/CTN
