Automotive Car Body Paint Booth

FOB Reference Price: Get Latest Price

≥1 Pieces

US $2000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

product name:: car body paint booth

inside dimension:: 6900*3900*2650mm

outside dimension:: 7020*5350*3350mm

main door:: 3-folds 3000*2600mm

Color:: Silver

Quick Details

Place of Origin:: Guangdong, China

Brand Name:: Deric Car Body Paint Booth

Model Number:: DR-CP6 Car Body Paint Booth

product name:: car body paint booth

inside dimension:: 6900*3900*2650mm

outside dimension:: 7020*5350*3350mm

main door:: 3-folds 3000*2600mm

Color:: Silver

Automotive Car Body Paint Booth

Features & Advantages:

1. Original Italian Burner

2. Unique big area air filtering system

3. External rotor centrifugal blower fan manufactured by Simens Technology

4. Safety device for air overpressure

5. Hot wind recycling system

6 . Custom design diesel fuel car spray booth

7 . E nvironmental,energy-saving spray paint room system

8 . C ustomize accepted

9. O ur diesel car spray booth provide you dust free space for your painting process and also have the good

performance for dry paint

10 . Good quality & after sale service

Technical data:

DR-CP6 C ar S pray B ooth Specification
Inside Dimension	6900×3900×2 65 0mm(L×W×H)
Outside Dimension	70 2 0×5350×3 35 0mm(L×W×H)
Main Door	3-folds, 3000×26 0 0mm(W×H)
Personal Door	1fold 80 0×1800mm(W×H)
Wall Panels	EPS (epispastics polystyrene) colorful steel skin board, wall panel: 6 0 mm thick tongue & groove style compound construction, Aluminum-alloy frame, anti-flame and heat-insulation, galvanized steel roof panel
Basement and Floor	Galvanized steel assemble, height is 280 mm, full grille floor, 2 pieces of ramps, 3 pieces of diamond plate construction.
Lighting	Ceiling lights:8units×4pieces=32pieces×36W; Side light s(optional)
Generator Setting Type	Side upper intake air, powder quadrate steel frame frame, coated steel.
Inlet Fan	1 × 5.5 KW double-intake centrifugal fans, air capacity:2 5 000 cm h
Exhaust Fan	1×5.5KW double-intake centrifugal fans, air capacity: 23 000 cm h
Heating System	1set: RIELLO G20 Diesel burner, 4-6minutes (from20 to 60º C) under baking status, max baking temperature is 80°C . S tainless steel heat exchanger, with anti-explosion hole for protection, electric damper from spraying to baking cycle.
Filter System	Dual filtering structure, the primary filter can capture granules larger than 10μm. Ceiling filter can capture granules bigger than 4μm. Its filtering rate reaches 98%. Air pressure balance gauge, TSP≤1.4mg/m3 floor filter(fiberglass filter).
Control System	Lighting switch, spraying, heat spraying, baking, temperature controller, time setting, emergency stop, temperature limit controller.
