Quick Details
-
Voltage:
-
24V
-
Dimension(L*W*H):
-
4250x1950x2500
-
Weight:
-
4500kgs
-
Air capacity:
-
22 M3/MIN
-
Feature:
-
compressor air portable
-
Air delivery:
-
22m3/min(777cfm)
-
Working pressure::
-
13bar(190psig)
-
Diesel engine:
-
YUCHAI YC6M340L-K20/250KW(340HP)
-
Diesel driven:
-
or Cummins 6LTAA8.9-C325/239KW(325HP)
-
Usage:
-
Drilling equipments,blasting,mining
-
Compression Stage:
-
Single
-
The head model no:
-
SKY192LH
-
Certification:
-
ISO14001-2004,ISO9001-2008
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
KAISHAN
-
Model Number:
-
LGCY-22/13
-
Voltage:
-
24V
-
Dimension(L*W*H):
-
4250x1950x2500
-
Weight:
-
4500kgs
-
Air capacity:
-
22 M3/MIN
-
Feature:
-
compressor air portable
-
Air delivery:
-
22m3/min(777cfm)
-
Working pressure::
-
13bar(190psig)
-
Diesel engine:
-
YUCHAI YC6M340L-K20/250KW(340HP)
-
Diesel driven:
-
or Cummins 6LTAA8.9-C325/239KW(325HP)
-
Usage:
-
Drilling equipments,blasting,mining
-
Compression Stage:
-
Single
-
The head model no:
-
SKY192LH
-
Certification:
-
ISO14001-2004,ISO9001-2008
KAISHAN LGCY-22/13 Diesel Engine Driven Screw Air Compressor For Drilling Rig Machine
Specifications for LGCY-22/13 Diesel Engine Driven Screw Air Compressor For Drilling Rig Machine:
| Model | LGCY-22/13 air Compressor |
| Capacity | 22 m³/min ( 777cfm) |
| Working Pressure | 13bar(189PSI) |
| Fluid Capacity | 65L |
| Compression Stage | Single |
| DIESEL ENGINE | |
| Diesel Engine Model No: |
YC6M340L-K20,250kW/ 6LTAA8.9-C325,239kW/ WD615.46,266kW |
| Capacity |
8.9L |
| Rated RPM |
1800 r/min |
| Unload RPM |
1400 r/min |
| Rated Power |
239KW(325HP) |
| Fuel Capacity |
400L |
| PACKAGE | |
| Noise Level dB(a) |
80±3 |
| Outlet connection |
G2 × 1, G3/4 × 1 |
| Wheel Size x Qty |
6.5-16x4 |
| Weight | 4500kgs |
| Dimension |
4250×1950×2500 (mm) |
Quick Details for LGCY-22/13 Compressor Air
| Place of Origin: Zhejiang China (Mainland) | Brand Name: kaishan | Model Number: LGCY-22/13 |
| Type: Screw | Configuration: Lg Air Compressor | Power Source: Diesel power |
| Lubrication Style: Oil-less | Mute: Yes |
| Packaging Detail: |
Nude packing |
| Delivery Detail: | 10-30 days after payment |
Advantages of the lg Air Compressor:
1- Air end of the compressor air:
Large diameter rotor, air end connect with diesel engine through coupling and no reduction
gear inside, more reliability, the rotate speed is same with the diesel engine's, more longer lifespan
2- Diesel engine of lg Air Compressor :
Select the diesel engine of COMMINS and YUCHAI brand, satisfy the emission
requirement of Europe, low oil consumption, after sale service system all over the china
3- Good adaptability:
T he Compressor air portable Automatically control the air delivery of diesel engine by matching the demand of air
consumption, which equal to frequency conversion control in motor power screw air compressor
The Inner Structure of LGCY-22/13 Compressor air portable:
The Related KAISHAN Silent Air Compressor :
| Model | Capacity (m3/min) | Exhaust pressure (Mpa) | Reted power(kw) | Weight (kgs) | Size (mmxmmxmm) |
| LGCY-6/7 | 6 | 0.7 | YCD4B22-95,70kW | 1400 | 3750×1920×1700 |
| LGCY-7.5/7 | 7.5 | 0.7 | YC4D80-K20,58kW | 1850 | 3900×1920×1700 |
| LGCY-8.5/14 | 8.5 | 1.4 | 4BTA3.9-C125,93kW | 1900 | 3900×1920×1900 |
| LGCY-9/7 | 9 | 0.7 | YC4D95Z-K20,70kW | 1850 | 3900×1920×1700 |
| LGCY-9/14 | 9 | 1.4 | YC6B150Z-K20,110KW | 2380 | 4080×1980×2350 |
| LGCY-9/14.5 | 9 | 1.45 | YC6B150Z-K20,110kW | 2380 | 3970×1940×2350 |
| LGCY-10/7 | 10 | 0.7 | YC4D95Z-K20,70kW | 1900 | 3900×1920×1700 |
| LGCY-10/10 | 10 | 1 | 4BTA3.9-C125,93kW | 1900 | 3900×1920×1900 |
| LGCY-12/7 | 12 | 0.7 | 4BTA3.9-C125,93kW | 2050 | 3900×1920×1900 |
| LGCY-12/7A | 12 | 0.7 | YC4A125Z-T10,92kW | 2050 | 4000×1980×1900 |
| LGCY-12/10 | 12 | 1 | YC6B150Z-K20,110kW | 2380 | 4080×1980×2350 |
| LGCY-12/12 | 12 | 1.2 | EQ6BT5.9-C160,118kW | 2380 | 4080×1980×2350 |
| LGCY-13/17 | 13 | 1.7 | 6CTA8.3-C215,158kW | 2380 | 3780×1980×2350 |
| LGCY-13/13 | 13 | 1.3 | 6BTA5.9-C180,132kW | 2750 | 3450×1520×2220 |
| LGCY-13/13A | 13 | 1.3 | YC6A190Z-T10,140kW | 2750 | 3450×1520×2220 |
| LGCY-15/13 | 15 | 1.3 | WD415.23,166kW | 3350 | 3380×1650×2500 |
| LGCY-15/13A | 15 | 1.3 | YC6A240-20,177kW | 3350 | 3380×1650×2500 |
| LGCY-16/13 | 16 | 1.3 | 6CTA8.3-C215,158kW | 3700 | 3980×1800×2450 |
| LGCY-16/17 | 16 | 1.7 | 6CTA8.3-C260,194kW | 3700 | 3650×1800×2500 |
| LGCY-17/7 | 17 | 0.7 | 6BTA5.9-C180,132kW | 3050 | 3380×1640×2350 |
| LGCY-17/14.5 | 17 | 1.45 | 6CTA8.3-C260,194kW | 3700 | 3980×1800×2450 |
| LGCY-18/17 | 18 | 1.7 | 6CTA8.3-C260,194kW | 3700 | 3980×1800×2450 |
| LGCY-18/19 | 18 | 1.9 | CUMMINS 6CTA8.3-C260 | 3700 | 3980*1800*2450 |
| LGCY-18/19A | 18 | 1.9 | YC6M260L-K20 | 3700 | 3980*1800*2450 |
| LGCY-21/35 | 21 | 3.5 | CUMMINS QSZ13-C500 | 5000 | 4600x1950x2600 |
| LGCY-21/35A | 21 | 3.5 | YC6K500L | 5000 | 4600x1950x2600 |
| LGCY-22/8 | 22 | 0.8 | 6CTA8.3-C260,194kW | 4000 | 4580×1950×2600 |
| LGCY-22/14 | 22 | 1.4 | YC6M340L-K20,250kW | 4500 | 4580×1950×2600 |
| LGCY-22/14K | 22 | 1.4 | 6LTAA8.9-C325,239kW | 4500 | 4580×1950×2600 |
|
LGCY-22/13
|
22 | 1.3 | YC6M340L-K20,250kW | 4500 | 4250×1950×2500 |
| LGCY-22/13K | 22 | 1.3 | 6LTAA8.9-C325,239kW | 4500 | 4250×1950×2500 |
| LGCY-22/13S | 22 | 1.3 | WD615.46,266kW | 4500 | 4250×1950×2500 |
| LGCY-22/20 | 22 | 2 | NTA855-P400,298kW | 4850 | 4450×1950×2650 |
| LGCY-22/20K | 22 | 2 | 6LTAA8.9-C360,265kW | 4500 | 4600×1950×2850 |
| LGCY-22/20A | 22 | 2 | YC6M340L-K20 | 4850 | 4600*1950*2850 |
| LGCY-26/20 | 26 | 2 | NTA855-P400,298kW | 4850 | 4450×1950×2650 |
| LGCY-26/20 | 26 | 2 | CUMMINS 6LTA8.9-C360 | 4500 | 4600*1950*2850 |
| LGCY-26/25 | 26 | 2.5 | CUMMINS QSZ13-C500 | 5000 | 4600x1950x2600 |
| LGCY-26/25A | 26 | 2.5 | YC6K500L | 5000 | 4600x1950x2600 |
| LGCY-26/35 | 26 | 3.5 | CUMMINS QSZ13-C550 | 6800 | 4700*2100*2850 |
| LGCY-26/35A | 26 | 3.5 | YC6K550L | 6800 | 4700*2100*2850 |
| LGCY-27/10 | 27 | 1 | YC6M340L-K20,250kW | 5000 | 4600×1950×2850 |
| LGCY-27/20 | 27 | 2 | YC6M395L-K20 | 4850 | 4600*1950*2850 |
| LGCY-27/22 | 27 | 2 | CUMMINS NTA855-P400 | 4850 | 4600*1950*2850 |
| LGCY-33/25 | 33 | 2.5 | CUMMINS QSZ13-C550 | 6800 | 4700*2100*2850 |
| LGCY-33/25A | 33 | 2.5 | YC6K550L | 6800 | 4700*2100*2850 |
| LGCY-33/35 | 33 | 3.5 | CUMMINS KTA19-P630 | 6800 | 4700*2100*2850 |
| LGCY-33/35A | 33 | 3.5 | PETER CULLER C-18ACERT | 6800 | 4700*2100*2850 |
| LGCY-39/25 | 39 | 2.5 | CUMMINS KTA19-P630 | 6800 | 4700*2100*2850 |
| LGCY-39/25A | 39 | 2.5 | PETER CULLER C-18ACERT | 6800 | 4700*2100*2850 |
About Kai Shan Group:
1- Established in 1956 ,Specialized in this line more than 50 years.
2- National Free-inspection Product.
3-Have advanced machining centers, automatic production line shape and heat treatment equipment setc 500 sets from the United Kingdom,United States,Japan,Germany etc.
4-Exported to Asia/South America/Mongolia/ Russia/ South-Africa etc . Have global customers.
5-Has got ISO900:2008 and many quality system certificates.
