Quick Details
-
Water flow:
-
Hot≤80°C Cold ≥1°C
-
Waterway connection:
-
G1/2", G3/8"
-
Solenoid valve lifetime:
-
> 500, 000 times
-
Respond time:
-
Open ≤ 0.5s Close ≤ 1s
-
Certification:
-
CE /WRAS Pending
-
Applicable ambient temperature:
-
1-45℃
-
Power supply:
-
DC:2CR5 6V
-
Warranty:
-
2 years, free spare parts will be supplied within two years
-
Surface Finishing:
-
Chrome
Quick Details
-
Valve Core Material:
-
Brass
-
Place of Origin:
-
Zhejiang, China
-
Material:
-
Zinc alloy
-
Water flow:
-
Hot≤80°C Cold ≥1°C
-
Waterway connection:
-
G1/2", G3/8"
-
Solenoid valve lifetime:
-
> 500, 000 times
-
Respond time:
-
Open ≤ 0.5s Close ≤ 1s
-
Certification:
-
CE /WRAS Pending
-
Applicable ambient temperature:
-
1-45℃
-
Power supply:
-
DC:2CR5 6V
-
Warranty:
-
2 years, free spare parts will be supplied within two years
-
Surface Finishing:
-
Chrome
|
Operating power |
DC:2CR5 6V |
|
Material |
Zinc alloy |
|
Surface treatment |
Chrome polished |
|
Applicable Water Pressure |
0.05-0.7MPa |
|
Applicable Ambient Temperature |
1-45ºC |
|
Applicable Water Temperature |
Hot≤80°C Cold ≥1°C |
|
Water flow |
4-6L/M (0.3Mpa) |
|
Inlet water Connection size |
G1/2", G3/8" |
|
Solenoid Valve lifetime |
> 500, 000 times |
|
Recognition Time |
Open≤0.5s Close≤1s |
|
Certification |
CE |
|
Warranty |
2 years, free spare parts will be supplieied within 2 years |
Note:
1.All parts are included inside the faucet body. Water temperature is adjustable from the faucet.
2.Designed with SCM, it is intelligent and induce rapidly. Stop water automatically when water flowing exceed 1 minute.Induce distance can be adjusted free of touching. Water inlet installed with strainer, it can be removed and clean to prevent valve.
3.Power supply: a: DC 6V, b: AC 110V-240V, c: AC/DC auto switch: when AC power off, DC will supply power automatically, and when AC power on, DC will switch to AC.
Packing: 8pcs/ctn
Inner box size: 39x21.5x9.5cm
Carton size: 45x40x32.5cm
Carton weight: N.W.: 12.5kgs G.W.: 13.1kgs
Four Core Technologies Of Intelligent Sanitary Ware
