Quick Details
-
Brand Name:
-
customized
-
Model Number:
-
SC-RDS2
-
Max. Current:
-
1600A
-
Item type:
-
Switches
-
Warranty:
-
1 Year
-
Function:
-
ON-OFF-ON
-
Relative humidity:
-
≤90%
-
Electrical Level:
-
PC
-
Poles:
-
3/4P
-
External closing instructions::
-
Active
-
ATS Operation type:
-
ATS dual power switch
-
Frequency:
-
50/60Hz
-
Power Loss:
-
≤10W
-
Certification:
-
CE ROHS
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
400V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
customized
-
Model Number:
-
SC-RDS2
-
Max. Current:
-
1600A
-
Item type:
-
Switches
-
Warranty:
-
1 Year
-
Function:
-
ON-OFF-ON
-
Relative humidity:
-
≤90%
-
Electrical Level:
-
PC
-
Poles:
-
3/4P
-
External closing instructions::
-
Active
-
ATS Operation type:
-
ATS dual power switch
-
Frequency:
-
50/60Hz
-
Power Loss:
-
≤10W
-
Certification:
-
CE ROHS
Foreword
Thanks for using our company products. We will provide reliable quality and dedicated service to allow you to rest assured to use our company products. Before installation, circuit connection, running and maintenance, please make sure to read carefully the user manual, to ensure the correct using, during using please also make sure know very well of relative safety and caution items.
Model Definition
Function Instruction
Installation
Dimensions
| In | A | A1 | B | B1 | C | E | G | J | K | L | N | P | R | S | T | U | W | ΦX | Y | Y1 |
| 1000A | 760 | 633 | 357 | 250 | 363 | 350 | 443 | 613 | 220 | 11 | 87 | 120 | 60 | 69 | 8 | 250 | 207 | 12.5 | 109 | 255 |
| 1250A | 760 | 633 | 357 | 250 | 363 | 350 | 443 | 613 | 220 | 11 | 87 | 120 | 80 | 69 | 8 | 250 | 207 | 13 | 110 | 255 |
| 1600A | 760 | 633 | 357 | 250 | 363 | 350 | 443 | 613 | 220 | 11 | 87 | 120 | 80 | 69 | 10 | 250 | 207 | 13 | 110 | 255 |
