Quick Details
-
Brand Name:
-
B&J
-
Model Number:
-
Plastic Box 200X150X100
-
External Size:
-
150*200*75 mm
-
Material:
-
ABS, ABS or PC
-
Product Name:
-
Outdoor Junction Box
-
OEM:
-
Offered
-
Package:
-
Carton/Pallets
-
Certification:
-
CE,IEC,ROHS,TUV
-
Quality:
-
Excellent
-
Temperature Range:
-
-40℃ to 80℃
-
Lock:
-
With Screws
-
Color:
-
RAL7032
-
Main Products:
-
Distribution Box,Stainless Steel Box, Plastic Junction Box,etc.
Quick Details
-
Protection Level:
-
IP68
-
Type:
-
Junction Box
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
B&J
-
Model Number:
-
Plastic Box 200X150X100
-
External Size:
-
150*200*75 mm
-
Material:
-
ABS, ABS or PC
-
Product Name:
-
Outdoor Junction Box
-
OEM:
-
Offered
-
Package:
-
Carton/Pallets
-
Certification:
-
CE,IEC,ROHS,TUV
-
Quality:
-
Excellent
-
Temperature Range:
-
-40℃ to 80℃
-
Lock:
-
With Screws
-
Color:
-
RAL7032
-
Main Products:
-
Distribution Box,Stainless Steel Box, Plastic Junction Box,etc.
Products Description
● Characteristic:Waterproof,dustproof,corrosionresistance,impact resistance
● IP Level:IP67
·● Impact Level:IK08
● Temp Range:ABS:-20~+70℃ PC:-40~+110℃
ANTI-SHEDDING DESIGN
Effectively avoid the problem of missing screws,especially when workong at height,to prevent the screws from falling.
HIGH GUALITY SEAL
Reinforced sealing ring made of high quality poly-methane material.
High corrosion resistance,better waterproof,long-term use of the box will not turn yellow.
TERMINAL
The series has a binding post for the user to install the circuit borad and the guide rail and the bottom plate.
|
product type
|
Height(mm)
|
Width(mm)
|
Deepth(mm)
|
N.W(KG)
|
|
BJ-PT-0811 W/PL
|
80
|
110
|
70
|
0.19
|
|
BJ-PT-0811-2 W/PL
|
80
|
110
|
85
|
0.20
|
|
BJ-PT-0813 W/PL
|
80
|
130
|
70
|
0.22
|
|
BJ-PT-0813-2 W/PL
|
80
|
130
|
85
|
0.24
|
|
BJ-PT-0818 W/PL
|
80
|
180
|
70
|
0.29
|
|
BJ-PT-0825 W/PL
|
80
|
250
|
70
|
0.37
|
|
BJ-PT-0825-2 W/PL
|
80
|
250
|
85
|
0.38
|
|
BJ-PT-1212 W/PL
|
125
|
125
|
75
|
0.27
|
|
BJ-PT-1212-2 W/PL
|
125
|
125
|
100
|
0.33
|
|
BJ-PT-1217 W/PL
|
125
|
175
|
75
|
0.46
|
|
BJ-PT-1217-2 W/PL
|
125
|
175
|
100
|
0.48
|
|
BJ-PT-1714 W/PL
|
170
|
140
|
100
|
0.53
|
|
BJ-PT-1520 W/PL
|
150
|
200
|
75
|
0.51
|
|
BJ-PT-1520-2 W/PL
|
150
|
200
|
100
|
0.56
|
|
BJ-PT-1525 W/PL
|
150
|
250
|
100
|
0.70
|
|
BJ-PT-1525-2 W/PL
|
150
|
250
|
130
|
0.81
|
|
BJ-PT-2020 W/PL
|
200
|
200
|
95
|
0.93
|
|
BJ-PT-2020-2 W/PL
|
200
|
200
|
130
|
0.89
|
|
BJ-PT-1928 W/PL
|
190
|
280
|
130
|
0.99
|
|
BJ-PT-2216 W/PL
|
220
|
165
|
125
|
0.75
|
|
BJ-PT-2838 W/PL
|
280
|
380
|
130
|
1.87
|
Purpose
Other Sizes,Cut-Outs And Drilled Holes According To Your Requirements
Installation Instructions
Installation method (1)
Use a screwdriver to go directly through the screw hole and install it on the wall.
Installation method (2)
The product can be fixed on the wall through hanging angle
Installation method (3)
The product can be fixed on any fixed column
