Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
DL
-
Model Number:
-
LN-880
-
Warranty:
-
12 Months
Quick Details
-
Motor Power:
-
0.75KW/1.1KW/1.5KW
-
Operating Pressure:
-
8-10Bar
-
Power Supply:
-
380V/220V/110V
-
Place of Origin:
-
China
-
Brand Name:
-
DL
-
Model Number:
-
LN-880
-
Warranty:
-
12 Months
Optional configuration:
Extra-large displacement Universal-direction blade Two gears for inflation controlled by one switch
Function:
Scope of application:
This product is suitable for semi-automatic changing tires of all kinds of small and medium-sized cars,rim diameter between 12"-28"
Product features:
1.Dismount and mount tires with push--pull arm.
2.The column goes backwards pneumatically,pneumatic push-pull locking automatically.
3.It uses axle to fix tires,ensuring no damage to wheels.
4.Automatic controlled demount/mount head(optional)
Product function:
1.The demount/mount head,made of special steel and four times harder than traditional stainless steel mounting head,is lifelong warranty.
2.The haxagon shaft is processed by 250t press machine.this once process keeeps its angle precise and stable.
3.The mounting head,crowbar and spade are all equipped with plastic protectors,which ensures no damage to wheel rims.
4.Bead breaker arm structure optimization increases the bead break power by 1.5 times.
5.Drawer pedal design makes it easy t oassemble and convenient after sale service.
6.The box is made thicker which ensures it stability and strength.
7.200mm alumnium alloy is more powerful for bead breaking.It can work for 500,000 times.
8.Longer bar of alumnium alloy cylinder is suitable for for the wide wheel.
9.The central axle can fix tires with one gentle twist.This simple structure reduce fault-rate while working.
10.The axle plate can be adjusted up and down easily according to width of tires.
11.This product gained Europe CE certificate
Technical Parameter | Technical Parameter |
Rim clamp from outside 10"-28" | Working Voltage: 415V/380V/220V/110V |
Max. Wheel Diameter 1200mm | Power 1.0KW/1,5KW |
Tire width 3"-15" | Machine Weight 300kg |
Working pressure 8-10bar |
