Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Tobole
-
Model Number:
-
TP- OB1-50WC2-1
-
Beam Angle(°):
-
120
-
CRI (Ra>):
-
80
-
Input Voltage(V):
-
90-305V
-
Lamp Luminous Efficiency(lm/w):
-
135
-
Lamp Luminous Flux(lm):
-
6750
-
Working Temperature(℃):
-
-40-60
-
Lifespan (hours):
-
80000
-
Working Time (hours):
-
80000
-
Product Weight（kg）:
-
3.9
-
Size:
-
L560*W196*H99 mm
-
Power:
-
50W
-
THD (Typical value):
-
<8%
-
LED Source:
-
Epistar SMD 3030
-
Working Frequency:
-
50/60Hz
-
Pole diameter:
-
60
Quick Details
-
Color Temperature(CCT):
-
2700-6500K
-
Warranty(Year):
-
5-Year
-
Lighting solutions service:
-
Lighting and circuitry design, DIALux evo layout, Agi32 layout, Project Installation
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Tobole
-
Model Number:
-
TP- OB1-50WC2-1
-
Beam Angle(°):
-
120
-
CRI (Ra>):
-
80
-
Input Voltage(V):
-
90-305V
-
Lamp Luminous Efficiency(lm/w):
-
135
-
Lamp Luminous Flux(lm):
-
6750
-
Working Temperature(℃):
-
-40-60
-
Lifespan (hours):
-
80000
-
Working Time (hours):
-
80000
-
Product Weight（kg）:
-
3.9
-
Size:
-
L560*W196*H99 mm
-
Power:
-
50W
-
THD (Typical value):
-
<8%
-
LED Source:
-
Epistar SMD 3030
-
Working Frequency:
-
50/60Hz
-
Pole diameter:
-
60
Features:
* Universal voltage:90-305VAC(50Hz/60Hz)
* High quality Epistar 3030.Excellent Optical
* High quality Epistar 3030.Excellent Optical
* Internal safety isolated driver,Automatic temperature detection.PF>0.9,THD<8%.
* Die casting aluminum，Anodized surface,fadeless and corrosion resistant.
* Special heat dissipation structure/Flow linear design,excellent heat dissipation performance.
* Widely used in highway,Urban main road,station,Square,Gym,wharf,residential area and other occasions.
* IP Grade：IP65 IP66，comply with CE,RoHSStandard
* 5years warranty
* Die casting aluminum，Anodized surface,fadeless and corrosion resistant.
* Special heat dissipation structure/Flow linear design,excellent heat dissipation performance.
* Widely used in highway,Urban main road,station,Square,Gym,wharf,residential area and other occasions.
* IP Grade：IP65 IP66，comply with CE,RoHSStandard
* 5years warranty
Product Description
Specification
|
Model
|
TP- OB1-50WC2-1
|
TP- OB1-100WC2-1
|
TP- OB1-150WC2-1
|
||
|
Power
|
50W
|
100W
|
150W
|
||
|
Size
|
L560 * W196 * H99 mm
|
L610 * W245 * H99 mm
|
L661 * W245 * H99 mm
|
||
|
Lumen
|
135LM/W
|
|
|
||
|
Beam angle
|
ＴＹＰＥ-Ⅱ/Ⅲ/Ⅳ/Ⅴ(optional)
|
|
|
||
|
Material
|
Die casting aluminum+PC lens
|
|
|
||
|
Interface Diameter
|
φ60mm/φ45mm（optional）
|
|
|
||
50W Size
Test Data
Installation .
Packing&Shipping
EPE+Carton box, 595*225*160mm(1Pcs/CTN), Product N*W：3.4KG , G*W:3.9KG/CTN
Installation Instruction
★Before Installation,Ensure the voltage,Frequency is consistent with the voltage range specified on the product label.
★Must be installed and operated by qualified professionals,Read installation instruction carefully.
★Make sure the lamp installed firmly and wiring correct,To avoid short circuit to damage the lamp causing fire.
★Do not operate with electricity,
★Please check the circuit after installation then power on test, to avoid electric shock
★Must be installed and operated by qualified professionals,Read installation instruction carefully.
★Make sure the lamp installed firmly and wiring correct,To avoid short circuit to damage the lamp causing fire.
★Do not operate with electricity,
★Please check the circuit after installation then power on test, to avoid electric shock
Caution
* Make sure the ceiling or post can support the weight of lamp.
* The accessories must be installed firmly.
* Please check the circuit after installation then power on to do test,to avoid electric shock.
* Do not open the lamp privately to change the electrical structure,In case damage the lamp,The resulting damage is not covered
by the warranty.
* Do not soak the lamp into the water directly.
* Do not look at the lamp for long time to protect the eyes from damage.
* The accessories must be installed firmly.
* Please check the circuit after installation then power on to do test,to avoid electric shock.
* Do not open the lamp privately to change the electrical structure,In case damage the lamp,The resulting damage is not covered
by the warranty.
* Do not soak the lamp into the water directly.
* Do not look at the lamp for long time to protect the eyes from damage.
When the lamp can not work properly
★If the lamp can not work,Please cut off the power source to check if the wiring and voltage is correct.
★If confirmed the wiring and voltage is normal and No appearance. damage,Please contact the dealer and customer service for warranty.
★If confirmed the wiring and voltage is normal and No appearance. damage,Please contact the dealer and customer service for warranty.
After-sales service and repair:
* In any case, if there is a problem, please contact your dealer or service center immediately.
* This product is repaired free of charge during the warranty period, and the appropriate material fee will be charged after the expiration of the warranty period.
The company provides a hotline to answer various questions from users. Please call at 0755-28151799or email to info@toplightled.com
* This product is repaired free of charge during the warranty period, and the appropriate material fee will be charged after the expiration of the warranty period.
The company provides a hotline to answer various questions from users. Please call at 0755-28151799or email to info@toplightled.com
