Quick Details
-
Production Capacity:
-
high
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Toolstar
-
Voltage:
-
380V/415V/440V
-
Dimension(L*W*H):
-
11055*7282*6300
-
Weight:
-
62000 kg
-
Marketing Type:
-
New Product 2023
-
Wire diameter:
-
7.3mm
-
Slot pitch:
-
9.5
-
Slab thickness:
-
20.5/30/39.5/49/58.5/68/77.5/87/96.5
-
Driving wheel diameter:
-
1200mm
-
Driven wheel diameter:
-
1200mm
-
Lifting stroke:
-
2300mm
-
Horizontal stroke:
-
9500
-
Size of trolley:
-
3.2*2.5
-
Tensioning:
-
Hydraulic tensioning
Quick Details
-
Type:
-
Stone Cutting Machine
-
Power:
-
37kw-280kw, 37Kw-280kw
-
Cutting thickness (max):
-
2050.5mm
-
Production Capacity:
-
high
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Toolstar
-
Voltage:
-
380V/415V/440V
-
Dimension(L*W*H):
-
11055*7282*6300
-
Weight:
-
62000 kg
-
Marketing Type:
-
New Product 2023
-
Wire diameter:
-
7.3mm
-
Slot pitch:
-
9.5
-
Slab thickness:
-
20.5/30/39.5/49/58.5/68/77.5/87/96.5
-
Driving wheel diameter:
-
1200mm
-
Driven wheel diameter:
-
1200mm
-
Lifting stroke:
-
2300mm
-
Horizontal stroke:
-
9500
-
Size of trolley:
-
3.2*2.5
-
Tensioning:
-
Hydraulic tensioning
|
ΦWire diameter(mm)
|
Φ4.3
|
|
|
|
|
||||
|
Slotpitch(mm)
|
8.6
|
|
8.5
|
|
8.4
|
||||
|
Slab thickness/(mm)
|
21.1
29.8
|
|
20.8
29.4
|
|
20.5
29
|
||||
|
Power(kW)
|
42 wires 132Kw
|
56 wires 160Kw
|
64wires 200Kw
|
72 wires 220Kw
|
80wires 250Kw
|
||||
|
Driving wheel diameter( mm )
|
Φ1200
|
|
|
|
|
||||
|
Driven wheeldiameter (mm )
|
Φ1200
|
|
|
|
|
||||
|
Lifting stroke (mm )
|
2300
|
|
|
|
|
||||
|
Horizontal stroke (mm)
|
9500
|
|
|
|
|
||||
|
Size oftrolley ( m)
|
3.2*2.5(Two)
|
|
|
|
|
||||
|
Tensioning
|
Hydraulic tensioning
|
|
|
|
|
||||
|
Tension force ( kgf)
|
160-200
|
|
|
|
|
||||
|
Wire speed
|
0-35m/s
|
|
|
|
|
||||
|
Wire length ( m)
|
21.52土0.02m
|
|
|
|
|
||||
|
Cutting area Wx H(m)
|
3.6x2.2
|
|
|
|
|
||||
|
Max. cutting width ( mm )
|
42wires 1075.1
|
56wires 1440.5
|
64 wires 1649.3
|
72 wires 1858.1
|
80wires 2066.9
|
||||
|
Dimension Lx H(mm)
|
11055x6300
|
|
|
|
|
||||
|
Weight (t)
|
42wires 45
|
56 wires
50
|
64 wires 53
|
72 wires
56
|
80wires
59
|
||||
FAQ
Q
:Can the design be customized?
A : Yes, we can offer the design based on the customers' requirements ,to match different block sizes and different slab thicknesss;
A : Yes, we can offer the design based on the customers' requirements ,to match different block sizes and different slab thicknesss;
Q :How do you provide after-sale service?
A : We have an experienced after-sales service team with more than 20 technicians ready for the buyers in 24hours to give them the reasonable suggestions and travel on site if necessary.
Q :What kind of wire saws you can supply for the multi wire machines?
A : We have 4.3mm/5.3mm/6.3mm/7.3mm wire saws for your options depends on your stone hardness and requirements.
Q :How is the leadtime?
A : Normally 90-120 days depending on the production plan .
