Quick Details
-
Standard form:
-
DMR/FM/DMR+FM
-
Channel Capacity:
-
8CH
-
Operating Voltage:
-
DC12V-24V
-
Dimension:
-
280*210*75mm
-
Weight:
-
2624g
-
Output power:
-
10W
-
Digital modulation:
-
4FSK
-
DMR Protocol:
-
ETSI-TS102 361-1,-2,-3
-
Adjacent channel selectivity:
-
≥70dB(25KHz)/≥60dB(12.5KHz)
-
Inter-modulation:
-
≥60dB/≥65dB
Quick Details
-
Brand Name:
-
wingstel
-
Model Number:
-
WTH-009
-
Place of Origin:
-
Guangdong, China
-
Standard form:
-
DMR/FM/DMR+FM
-
Channel Capacity:
-
8CH
-
Operating Voltage:
-
DC12V-24V
-
Dimension:
-
280*210*75mm
-
Weight:
-
2624g
-
Output power:
-
10W
-
Digital modulation:
-
4FSK
-
DMR Protocol:
-
ETSI-TS102 361-1,-2,-3
-
Adjacent channel selectivity:
-
≥70dB(25KHz)/≥60dB(12.5KHz)
-
Inter-modulation:
-
≥60dB/≥65dB
| Frequency | UHF:TX 463.3125MHz / RX 453.3125MHz |
| VHF:TX 162.6125MHz / RX 152.6125MHz | |
| Customize:136-174MHz/400-470MHz | |
| Note: Transmit and receive frequencies to be customized | |
| Standard form | DMR/FM/DMR+FM |
| Channel Capacity | 8CH |
| Channel Spacing | ±12.5KHz Narrow/±25KHz Wide |
| Operating Temperature | -30℃~+60℃ |
| Operating Voltage | DC12V-24V |
| Antenna Impedance | 50Ω |
| Frequency Stability | ±0.5ppm |
| Dimension | 280×210×75mm |
| Weight | 2624g |
| Transmitter | |
| Output power | 10W |
| Transmission Current | ≤2.5A |
| FM Modulation | 11kφF3E/16kφF3E |
| Digital modulation | 4FSK |
| Modulation Distortion | ≤5% |
| FM Noise | ≥40dB(25KHz)/≥35dB(12.5KHz) |
| Adjacent Channel Power | ≥70dB(25KHz)/≥60dB(12.5KHz) |
| Audio Response | +1~-3dB |
| DMR Protocol | ETSI-TS102 361-1,-2,-3 |
| Receiver | |
| Analog receive Sensitivity | 0.25μν(12dB)SINAD |
| Digital receive sensitivity | -120dBm (BER≤5%) |
| Adjacent channel selectivity | ≥70dB(25KHz)/≥60dB(12.5KHz) |
| Inter-modulation | ≥60dB/≥65dB |
| Signal imitation | ≥70dB |
| Audio Response | +1~-3dB |
| Audio distortion | <5% |
| FM Noise |
≥45dB(25KHz)/≥40dB(12.5KHz) |
