Quick Details
-
Warranty:
-
1year
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
CQ or Customized
-
Model Number:
-
CQ-NOD14G-F16NA40
-
Weight:
-
240g
-
Effective Visual Distance:
-
180-220m
-
Image intensifier:
-
Gen2+
-
Resolution ratio:
-
57-64
-
SNR:
-
22-25
-
FOV:
-
40 degree
Quick Details
-
Size:
-
115x69x54mm
-
Type:
-
Monocular
-
Magnification:
-
1X
-
Warranty:
-
1year
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
CQ or Customized
-
Model Number:
-
CQ-NOD14G-F16NA40
-
Weight:
-
240g
-
Effective Visual Distance:
-
180-220m
-
Image intensifier:
-
Gen2+
-
Resolution ratio:
-
57-64
-
SNR:
-
22-25
-
FOV:
-
40 degree
Product Description
Specification
|
Model
|
CQ-NOD14G-F16NA40
|
|
Image intensifier
|
Gen2+ (High performance super second generation)
|
|
Optical magnification
|
1X
|
|
Resolution ratio
|
57-64
|
|
The cathode surface type
|
S25
|
|
Signal-to-noise ratio (decibel)
|
22-25
|
|
Optical sensitivity (microAnn / lumen)
|
600-800
|
|
Image Intensifier Warranty Resource
|
10,000
|
|
Field of view (degree)
|
40°
|
|
Observation distance (m)
|
180-220
|
|
Diopter adjustment range
|
+5/-5
|
|
Lens shift(objective lens)
|
F1.2, 25mm
|
|
Optical coating
|
Multi-layer composite broadband super-vacuum ion-permeable membrane
|
|
Objective adjustment range (m)
|
0.25--∞
|
|
Automatic anti-strong light
|
High-sensitive, ultra-fast, and broadband detection
|
|
Flip detection
|
Full-solid-state contactless automatic pose recognition
|
|
Overall dimensions (mm) (excluding eye mask)
|
115x 69x54
|
|
Product material
|
Full aviation aluminum alloy
|
|
Weight (g)
|
240g
|
|
Power supply voltage (V)
|
2.6-4.2V
|
|
Battery type (V)
|
One lithium battery
|
|
Continuous working hours (hrs)
|
20hrs (IR open) , 40hrs (IR closed)
|
|
Operating temperature range (℃)
|
-40℃~+50℃
|
|
relative humidity
|
5%-98%
|
|
Dust and waterproof grade
|
IP66
|
