Quick Details
-
Knitting Method:
-
Double
-
Computerized:
-
Yes
-
Gauge:
-
1.5 GG, 3 GG, 7 GG, 12 GG, 14 GG, 2 GG, Other, 16 GG, 9 GG, 5 GG, 10GG, 2.5GG, 18GG, 16GG, 8GG, 3-5-7 multi-gauge, 8-10-12 multi-gauge
-
Knitting width:
-
52 inch
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
TL
-
Power:
-
2 W
-
Weight:
-
1000 KG
-
Dimension(L*W*H):
-
2750*8500*1800MM
-
Marketing Type:
-
New Product
-
Standard:
-
CE standard
-
Intarsia:
-
available
-
Yarn feeder qty:
-
16
-
Voltage:
-
220
-
flat knitting machine style:
-
shima seiki or stoll style
Quick Details
-
Type:
-
jacquard
-
Production Capacity:
-
speed: max 1.2m/s
-
Knitting Style:
-
knitting
-
Knitting Method:
-
Double
-
Computerized:
-
Yes
-
Gauge:
-
1.5 GG, 3 GG, 7 GG, 12 GG, 14 GG, 2 GG, Other, 16 GG, 9 GG, 5 GG, 10GG, 2.5GG, 18GG, 16GG, 8GG, 3-5-7 multi-gauge, 8-10-12 multi-gauge
-
Knitting width:
-
52 inch
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
TL
-
Power:
-
2 W
-
Weight:
-
1000 KG
-
Dimension(L*W*H):
-
2750*8500*1800MM
-
Marketing Type:
-
New Product
-
Standard:
-
CE standard
-
Intarsia:
-
available
-
Yarn feeder qty:
-
16
-
Voltage:
-
220
-
flat knitting machine style:
-
shima seiki or stoll style
We are factory, not only produce the fabric, also produce the production.
We have more than
15
years experence,we aways offer more, make things better!
|
Guage:
|
5.7(Multi-gauge),5G,7G,8G,10G,12G,14G
|
|
Knitting width:
|
52”=132CM
|
|
Knitting speed:
|
max 1.2m/s (it depend the pattern and yarn quantity)
|
|
Knitting system:
|
single carriage with double system.
|
|
Knitting function:
|
transfer, tuck, pointer, intarsia, jacquard, hide, or apparent shaping and other regular or irregular patterns.
|
|
Racking:
|
controlled by servo motor racking within 2 inches and with fine adjusting function.
|
|
Encoder:
|
advanced encoder adopted.
|
|
Detect alarm system:
|
the safety alarm detect device, achieve to up-down and left-right swing function, which surmount the normal flat knitting machine with detect simply left-right swing only and great increase the detect protect function.
|
|
Transfer cam:
|
the transfer is compose designed, single or double cam system an other cam system for knitting which will achieve to high production efficiency knit.
|
|
Stitch density:
|
controlled by stepping motor with 24 sections, adjustable to different knitwear, have various of shaping and patterns. The adjustable range from 0-650.
|
|
Sinker system:
|
controlled by stepping motor, adjustable to different knitwear, have various of shaping and patterns.
|
|
Fabric rolling system:
|
controlled by stepping motor, 24 section force selection adjustable range from 0 to 100.
|
|
Yarn feeder:
|
2*8 yarn feeders on each side of 4 guide rails, shift able on any needle position ( special intarsia carriers optional if you need intarsia).
|
|
Protection:
|
The machine will auto alarm if yarn-breaking, knots, floating, yarn rewind, end of knitting, fail of racking, needle breakage and error programming occur. Also set up the safety auto-lock protect device.
|
|
Screen:
|
Adopt LCD touch screen and figure interface, input device: USB internal storage 1G, A great amount of design files can be stored at the same time and they can be fetches out for use at any time as per production requirement.
|
|
Monitoring menu:
|
Each kind of operation parament can be shown and it can be adjust at any time when the machine is running. Making conveniences for operations as much as possible.
|
|
Language version:
|
Chinese, English
|
|
Power;
|
single-phase 220V, adopt advanced CMOS technology, recovery of memory function as power shock stop (=0.6 KW/H)
|
|
Easy repair
|
The back door open by key, easy for repair.
|
|
Comb system
|
The comb moving by servo, so the force much steady.
|
|
Anti-interference
|
Use isolation transformer, prevent the power interference.
|
|
Measurement:
|
2750*8500*1800MM
|
|
Net weight:
|
1090KG
|
|
Goss weight:
|
1120KG
|
Q : Can I have sample order?
A :Yes,Free sample order is available for quality test. Customized sample, such as embroidery/prining/special gsm/special colors need pay sample fee.
Q : What is the lead time for sample?
A : Current sample needs 1-3 days, customized sample needs 7-15 working days according to your specific requirement.
Q : Can you produce OEM?
A : Yes, we can provide OEM according to customer's requests.
Q : Which payment do you accept?
A : Our usually payment is Paypal, Western Union, etc.
Q : What is your delivery time?
A : After received your deposit, it normally need 25 days. Depend your quantity and design.
Q : Which shipping method do you ship?
A : Express courier like DHL, TNT FedEx, UPS, EMS etc. Shipping time about 3-7 working days depends on country and area. By air port to port: about 7-12 days depends on port. By sea port to port: about 20-35 days.
Whatsapp/Telephone number: +86-186-9492-8899.
