Quick Details
-
Voltage:
-
380V
-
Power:
-
1.5 kw
-
Dimension(L*W*H):
-
1600*1875*1700 mm
-
Warranty:
-
1 Year
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Working width:
-
620 mm/1320 mm
-
Working thickness:
-
2-80 mm
-
Minimum length:
-
300 mm
-
Feeding speed:
-
0-20 m/min
-
Feeding power:
-
1.5 kw
-
Coater roller power:
-
1.5 kw
-
Coating power:
-
0.75 kw
-
Heating power:
-
1.5 kw
-
Certification:
-
CE ISO
Quick Details
-
Machine Type:
-
Roller coating machine, Painting Equipment, Coating Equipment
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Purete
-
Voltage:
-
380V
-
Power:
-
1.5 kw
-
Dimension(L*W*H):
-
1600*1875*1700 mm
-
Warranty:
-
1 Year
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Working width:
-
620 mm/1320 mm
-
Working thickness:
-
2-80 mm
-
Minimum length:
-
300 mm
-
Feeding speed:
-
0-20 m/min
-
Feeding power:
-
1.5 kw
-
Coater roller power:
-
1.5 kw
-
Coating power:
-
0.75 kw
-
Heating power:
-
1.5 kw
-
Certification:
-
CE ISO
Vacuum Metallizing Coating Machine
1. This machine is available to the base/surface paint coating for the furniture/flooring/cabinet/walling/decorative boards, which different materials like as wood/MDF/plastic/metal/glass/CaSi and so on.
2. It can ensure the surface of the paint to be smooth, with good plumpness, and with no chromatic difference.
3. The roller coater and the electronic roller and the conveyor controlled by separate motor/reducer/frequency, with best precision and stability.
4. It is easy to change the roller with the casting design.
5. It can be chosen with the PLC, automatic elevator, separate electronic box or more automatic choosing unit.
| Model | PRT-F1113 |
| Working width | 620 mm/1320 mm |
| Working thickness | 2-80 mm |
| Minimum length | 300 mm |
| Feeding speed | 0-20 m/min |
| Feeding power | 1.5 kw |
| Coater roller power | 1.5 kw |
| Coating power | 0.75 kw |
| Heating power | 1.5 kw |
| Application | Plywood, solid wood, particle board, HPL, PVC, WPC, SPC, metal, glass, plastic, ceramic tile, calcium silicate board, cement fiber board, gypsum board, melamine board, stainless steel, vermiculite board |
|
Delivery Time |
Standard Machine: One month. Customize Machine: Two months. |
After-sales Service Team
We would dispatch engineer go to customer's factory for machinery installation, start-up, testing and training the operators. We provide all life after-service for machinery.
