- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
IP-E1010
-
Dimension:
-
Dia194*131mm
-
Output Power:
-
10W/20W
-
Shell Material:
-
ABS
-
The body material:
-
ABS
-
Product Name:
-
IP system POE speaker
-
Type:
-
In-ceiling Speaker
-
Power Supply:
-
DC 12V/1.5A or use POE as power supply
-
Internet Interface:
-
Standard RJ45
-
Frequency Response:
-
80Hz~16KHz
-
SNR:
-
≥80dB
-
Protocol:
-
RTP, UDP, TCP/IP, FTP
-
Weight:
-
1.25kg
-
Keyword:
-
ip poe ceiling speaker
-
Application:
-
Hotel, School, Airport, Bank, Hospital
Quick Details
-
Warranty:
-
3months-1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ARVOX
-
Model Number:
-
IP-E1010
-
Dimension:
-
Dia194*131mm
-
Output Power:
-
10W/20W
-
Shell Material:
-
ABS
-
The body material:
-
ABS
-
Product Name:
-
IP system POE speaker
-
Type:
-
In-ceiling Speaker
-
Power Supply:
-
DC 12V/1.5A or use POE as power supply
-
Internet Interface:
-
Standard RJ45
-
Frequency Response:
-
80Hz~16KHz
-
SNR:
-
≥80dB
-
Protocol:
-
RTP, UDP, TCP/IP, FTP
-
Weight:
-
1.25kg
-
Keyword:
-
ip poe ceiling speaker
-
Application:
-
Hotel, School, Airport, Bank, Hospital
AI-9211 IP Public Address System IP POE Ceiling Speaker
Our Advantages
Products Description
Descriptions
* ABS flame retardant housing, iron mesh cover, one-way receiving terminal, digital decoding terminal and active smallpox horn in one;
* The equipment is designed with embedded computer technology and DSP audio processing technology.
* Built-in 1 network hardware audio decoding module, support TCP/IP, UDP, IGMP (multicast) protocol;
* Built-in Class D 20W amplifier circuit, fine sound quality, strong power;
* 5.25 inch horn unit, full band coverage, clear sound quality bright and pleasant;
* When equipped with POE-powered POE switch, only one network cable is required to connect, the construction is simple and the cost is low;
* POE switch supply power up to 10W, if using ordinary switch, then the external DC12V power adapter power up to 20W;
* With a one-way linkage output interface (short-circuit signal), easy to extend with other systems;
* Support DHCP, compatible with routers, switches, bridge gateways, the Internet, multicast, unicast and other arbitrary network structures;
* Built-in network isolation lightning treatment circuit
* ABS flame retardant housing, iron mesh cover, one-way receiving terminal, digital decoding terminal and active smallpox horn in one;
* The equipment is designed with embedded computer technology and DSP audio processing technology.
* Built-in 1 network hardware audio decoding module, support TCP/IP, UDP, IGMP (multicast) protocol;
* Built-in Class D 20W amplifier circuit, fine sound quality, strong power;
* 5.25 inch horn unit, full band coverage, clear sound quality bright and pleasant;
* When equipped with POE-powered POE switch, only one network cable is required to connect, the construction is simple and the cost is low;
* POE switch supply power up to 10W, if using ordinary switch, then the external DC12V power adapter power up to 20W;
* With a one-way linkage output interface (short-circuit signal), easy to extend with other systems;
* Support DHCP, compatible with routers, switches, bridge gateways, the Internet, multicast, unicast and other arbitrary network structures;
* Built-in network isolation lightning treatment circuit
|
Item NO.
|
IP-E1010
|
|
Network interface
|
Standard RJ45
|
|
Support agreements
|
RTP, UDP, TCP/IP, FTP
|
|
Audio format
|
MP3/WAV
|
|
Sample rate
|
8K to 48KHz
|
|
Network transmission rate
|
100Mbps
|
|
Audio mode
|
16-bit stereo CD sound quality
|
|
The horn unit specification
|
5.25″
|
|
Output frequency
|
80Hz to 16KHz
|
|
Harmonic distortion
|
≤1%
|
|
The signal-to-noise ratio
|
≥80dB
|
|
Rated power
|
10W (when POE is powered)
|
|
The ambient temperature
|
-20°C to 70°C
|
|
Ambient humidity
|
20% to 80% relative humidity
|
|
Power consumption
|
24W
|
|
Input power supply
|
POE/DC12V
|
|
Installation form
|
Ceiling type
|
|
Material
|
ABS flame retardant material
|
|
Cutout Size
|
Dia175mm
|
|
The size of the product
|
Dia194 x 131mm
|
|
Weight
|
1.25kg
|
Application
Factory:
Hotel:
School:
