Quick Details
-
Table Travel (Y) (mm):
-
1900mm
-
Dimension(L*W*H):
-
6500*5500*4500mm
-
Weight (T):
-
19 T
-
Table Travel (Z) (mm):
-
800mm
-
Positioning Accuracy (mm):
-
0.025/0.02/0.02
-
Repeatability (X/Y/Z) (mm):
-
0.02/0.015/0.015
-
Range of Spindle Speed(r.p.m):
-
1 - 6000 r.p.m
-
Spindle Motor Power(kW):
-
15/18.5kw
-
Max. Table Load(kg):
-
4000 kg
-
Tool Magazine Capacity:
-
24, 32, 40, 60
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
ADLV/SMTCL
-
Marketing Type:
-
Hot Product
-
Core Components:
-
Spindle
-
Gantry effective width:
-
1600mm
-
Spindle nose to table face:
-
190~990mm
-
Table T slot(no.-Size x Distance):
-
7-22x170
-
Sleeper Form and dimension:
-
T-Guide
-
Spindle form:
-
Direct coupling/gear head
Quick Details
-
Table Size (mm):
-
1300*2000mm
-
Number of Axes:
-
3
-
Table Travel (X) (mm):
-
2000mm
-
Table Travel (Y) (mm):
-
1900mm
-
Dimension(L*W*H):
-
6500*5500*4500mm
-
Weight (T):
-
19 T
-
Table Travel (Z) (mm):
-
800mm
-
Positioning Accuracy (mm):
-
0.025/0.02/0.02
-
Repeatability (X/Y/Z) (mm):
-
0.02/0.015/0.015
-
Range of Spindle Speed(r.p.m):
-
1 - 6000 r.p.m
-
Spindle Motor Power(kW):
-
15/18.5kw
-
Max. Table Load(kg):
-
4000 kg
-
Tool Magazine Capacity:
-
24, 32, 40, 60
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
ADLV/SMTCL
-
Marketing Type:
-
Hot Product
-
Core Components:
-
Spindle
-
Gantry effective width:
-
1600mm
-
Spindle nose to table face:
-
190~990mm
-
Table T slot(no.-Size x Distance):
-
7-22x170
-
Sleeper Form and dimension:
-
T-Guide
-
Spindle form:
-
Direct coupling/gear head
|
Parameters
|
Unit
|
XKW2316x20
|
XKW2316x30
|
XKW2316x40
|
||
|
Gantry effective width
|
mm
|
1600
|
1600
|
1600
|
||
|
X travel
|
mm
|
2000
|
3000
|
4200
|
||
|
Y travel
|
mm
|
1900
|
1900
|
1900
|
||
|
Z travel
|
mm
|
800
|
800
|
800
|
||
|
Spindle nose to table face
|
mm
|
190-990
|
190〜990
|
190-990
|
||
|
Table size （WxL）
|
mm
|
1300x2000
|
1300x3000
|
1300x4000
|
||
|
Max loading
|
kg
|
4T
|
5T
|
6T
|
||
|
Table Tslot(no.-Sizex Distance)
|
|
7-22x170
|
7-22x170
|
7-22x170
|
||
|
Sleeper Form and dimension
|
mm
|
T-Guide
|
T-Guide
|
T-Guide
|
||
|
Maximum spindle speed
|
rpm
|
6000rpm
|
6000rpm
|
6000rpm
|
||
|
Spindle power
|
kW
|
15/18.5
|
15/18.5
|
15/18.5
|
||
|
Spindle form
|
|
Direct coupling/gear head
|
|
|
||
|
Spindle cone hole
|
|
BT50
|
BT50
|
BT50
|
||
|
Cutter storage capacity
|
T
|
24/32/40/60
|
24/32/40/60
|
24/32/40/60
|
||
|
Maximum tool diameter
|
mm
|
0)125/230
|
0)125/230
|
0)125/230
|
||
|
Maximum tool length
|
mm
|
300
|
300
|
300
|
||
|
Maximum tool weight
|
kg
|
18
|
18
|
18
|
||
|
Total power supply capacity
|
kVA
|
50
|
50
|
50
|
||
|
Machine tool weight
|
T
|
19
|
23
|
26
|
||
|
Machine tool size
|
mm
|
6500x5500x4500
|
8500x5500x4500
|
10500x5500x4500
|
||
|
Numerical control system
|
|
SIEMENS 828D/FANUC Oi-MF
|
|
|
||
Q1：Is your company a manufacturer?
A1：Yes, we are a machine tool manufacturer, and we sell our own products.
Q2：What’s your payment terms?
A2：FOB, 50% downpayment after placing a P/O, and 50% payment before shipment, which is also negotiable as
per customer’s requirements.
Q3：What’s your delivery time?
A3：The delivery time ranges from 60 days to 90 days, which depends on the specific machine and its specific configurations. Please contact us to confirm whether the machine you order is in stock or to be produced.
Q4：Can we pay by L/C or others ？
A4：Yes ,you can make the payment by T/T , l/C etc.
Q5：What’s your warranty period?
A5：12 months.
Q6：Can you provide China agent service for your clients?
A6：Yes, we can take a live video tour of the factory and help customers establish a partner to visit various urban areas in China.
Q7：
Can you supply other international popular items?
A7：Yes, because we are an integrated company of industry and trade, we are able to provide international hot items in addition to our own products.
