Quick Details
-
Warranty:
-
1 year, 12 Months/1000 Hours
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
MG
-
Model Number:
-
MG1MGF
-
Speed:
-
1500RPM
-
Weight:
-
12000kg
-
SIZE:
-
6900*2200*2300(L*W*H mm)
-
Product Name:
-
Diesel Genertor
-
Starting system:
-
Electric 24 Volt DC
-
Phase:
-
Three Pahse
-
Alternator brand:
-
STC Dynamo Generator
-
Cooling method:
-
Water-cooling System
-
Certification:
-
ce
Quick Details
-
Rated Voltage:
-
220/380V
-
Rated Current:
-
1800A
-
Frequency:
-
50Hz
-
Warranty:
-
1 year, 12 Months/1000 Hours
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
MG
-
Model Number:
-
MG1MGF
-
Speed:
-
1500RPM
-
Weight:
-
12000kg
-
SIZE:
-
6900*2200*2300(L*W*H mm)
-
Product Name:
-
Diesel Genertor
-
Starting system:
-
Electric 24 Volt DC
-
Phase:
-
Three Pahse
-
Alternator brand:
-
STC Dynamo Generator
-
Cooling method:
-
Water-cooling System
-
Certification:
-
ce
Specification
|
Genearal
|
|
|
|
Unit model:MG1000GF
|
Steady state voltage adjustment rate (%):≤± 1
|
|
|
Output power:1000KW
|
Voltage fluctuation rate (%):≤ ± 0.5
|
|
|
Power factor:COSΦ = 0.8 (lagging)
|
Transient voltage adjustment rate (%):+20 ~-15
|
|
|
Output voltage:400V / 230V
|
Voltage stabilization time (s):≤1
|
|
|
Output current:1800A
|
Steady state frequency adjustment rate (%):≤ ± 1
|
|
|
Rated frequency:50Hz
|
Frequency fluctuation rate (%):≤ ± 0.5
|
|
|
Rated speed:1500rpm
|
Transient frequency adjustment rate (%):+ 10 ~ -7
|
|
|
Fuel grade:(standard) 0 # light diesel (normal temperature)
|
Frequency stabilization time (S):≤3
|
|
|
Dimensions:6900×2200×2300(L×W×H mm)
|
Fuel consumption (100% load):224g/kW·h
|
|
|
Start mode:12000kg
|
Acoustic noise (LP7m):95dB(A)
|
|
|
Technical parameters of diesel engine
|
|
|
|
Brand/origin:Cummins engine
|
Cooling method:Closed water-cooling
|
|
|
model:KTA50-G9
|
Oil supply method:direct injection
|
|
|
Number of cylinders / Dare to mention structure:12 / V Type
|
Speed regulation method:Electric
|
|
|
Bore stroke:159×159 mm
|
Intake method:Turbo
|
|
|
Compression ratio:14.5:1
|
Overload capacity:110%
|
|
|
Start mode:DC 24V Electric start
|
Speed:1500rpm
|
|
|
Technical parameters of generator:
|
|
|
|
Brand:China Stamford Copper Generator
|
Protection level:IP22
|
|
|
Model:HQF-1000
|
Wiring mode:Three-phase four-wire, Y-connection
|
|
|
Rated power:1000kW
|
Adjustment method:AVR (Automatic Voltage Regulator)
|
|
|
Rated voltage:400V / 230V
|
Output frequency:50Hz
|
|
|
Insulation class:H class
|
Output factor:COSΦ = 0.8 (lag)
|
|
|
Genset standard features
|
Optional accessories(Extra charged)
|
|
|
Ø Direct injection internal combustion engine(Diesel);
|
Ø Engine oil,diesel,water jacket,Anti-condensation heater;
|
|
|
Ø AC synchronous generator(Single Bearing);
|
Ø Battery floating charger;
|
|
|
Ø Water Radiator design for 40-45℃ Ambient belt-driven fans and guards;
|
Ø Self-protection unit/self-starting control panel;
|
|
|
Ø Generation output air switch,Standard control panel;
|
Ø Tree-remote control panel;
|
|
|
Ø Steel common base with shock absorber;
|
Ø ATS AUTO-loaded transferring screen;
|
|
|
Ø Dry-type air filter fuel filter,oil filter,starting motor,Self-charging alternator;
|
Ø Daily fuel tank,Integral fuel tank;
|
|
|
Ø starter battery and connecting cables;
|
Ø Waterproof type(Cabinet);
|
|
|
Ø Industrial 9dB muffler and accessories;
|
Ø Mobile trailer(Drip proof);
|
|
|
Ø The engine and alternator’s original technical papers,manuals and testing reports ship with GenSet;
|
Ø Mobile trailer(Silent type);
|
|
Product Description
Packing & Delivery
plywood case packing
