Quick Details
-
Weight:
-
370kg
-
Size:
-
1900*700*1620mm
-
Power:
-
3.5kw
-
Product name:
-
sodium hypochlorite plant
-
Function:
-
wastewater treatment
-
Usage:
-
salt water electrolysis
-
Application:
-
water treatment
-
Certification:
-
ISO9001
-
Capacity:
-
1200g/h active chlorine
-
salt consumption:
-
3.5kg per kg Cl2
-
power consumption:
-
4.0kw per kg Cl2
-
water treatment:
-
5000tons per day
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
GEEMBLUE
-
Material:
-
Carbon Steel with plastic spray, salt water, electricity
-
Weight:
-
370kg
-
Size:
-
1900*700*1620mm
-
Power:
-
3.5kw
-
Product name:
-
sodium hypochlorite plant
-
Function:
-
wastewater treatment
-
Usage:
-
salt water electrolysis
-
Application:
-
water treatment
-
Certification:
-
ISO9001
-
Capacity:
-
1200g/h active chlorine
-
salt consumption:
-
3.5kg per kg Cl2
-
power consumption:
-
4.0kw per kg Cl2
-
water treatment:
-
5000tons per day
Guangzhou Geemblue Environmental Equipment Co., Ltd. is a high-tech enterprise which devoting energy into the development and application of the most advanced water treatment technology. It holds 4 patents of inventions, 15 utility model patents , Appearance patent and a total of 21 software copyrights, besides that, Geemblue is also undertaking 15 research projects of Guangzhou local Government.
The company has been focusing on serving municipal utility plants, sewage treatment plants, power plants, oil platforms, mariculture and food processing plants, etc. and providing quality water treatment equipment and water treatment solutions, so far, the company has been a business partner of many large environmental companies at home and abroad.
Geemblue has always been promoting China's best water treatment equipment and technology, to build the fame of "Made in China". Every movement of Geemblue is for better water treatment equipment and Technology, and for the growth of "Made in China"
It's a system using SALT as raw material to produce SODIUM HYPOCHLORITE liquid ( 0.8%) and dose into water for disinfection.
Main Features
The system is fully auto-control by PLC center to produce sodium hypochlorite from salt and dose into water for disinfection
• Large adaptability to different brine qualities
• Lower energy consumption
• High strength sodium hypochlorite
• Can be washed in order to restore the original permeability
• Is harmless and environmental friendly, does not contain any restricted material
Onsite chlorination system titanium electrode of water electrolysis machine
Electrochlorination system Brine electrochlorination system of sodium hypochlorite generator for water treatment
Electrolytic Cell
Brand: Magneto ( World Top 3 Manufacturer )
Original: Holland
TA1 Pure titanium electrode, Coating with Ruthenium and Iridium Oxide, at least 5 years' coating service life and 18 years' electrode service life;
Transparency cell ensure the observation of the whole process and scaling inside.
Rectifier
Brand:
GEEMBLUE
Marine-leveled constant current rectifier, electric conversion efficiency>92%, Current sharing precision<1%, high efficiency and stability.
"Infineon" for IGBT, "An" for schottky diode, "Mitsubishi" for IGBT driver module.
Anti-corrosion, anti-moisture, anti-dust; alarm for over voltage/current, short circuit and overheat.
Machine Parts
Name:
Bliwing Cylinder
Brand:
FESTO
Original:
Germany
PLC and LCD touch screen we select "Siemens", electronic components we select "ABB" and "Schneider ", which ensure stable performance, Central control have RS485 communication interface, able to remote monitoring;
Anti-corrosion ,anti-moisture framework, Particularly suitable for high humidity, high salinity environment
.
Water Softener
Remove Calcium and magnesium ions , reduce electrode scaling;
The system can be operated, back flushed automatically, without manual operation.
Acid washing machine
Remove Scale, Protect the electrode from short circuits, ensure high efficient of electrolysis.
Auto dosing system
Closed-loop design include online residual chlorine analyser, PLC and metering pump, dosing amount can be adjusted automatically, accuracy dosing.
Module design, Convenience for dosing and maintenance.
Pre-Sales Service
Inquiry and consulting support.
Sample testing support.
View our Factory.
After-Sales Service
Your suggestion on our service is our forging power.
If the quality and quantity is not the same with your demands,please feel free to contact us,we will try our best to resolve it and give you the satisfying reply.
Q:Are you a factory or trading company
A:Factory
Q:How to buy your idea products?
A:Please supply water sources, water quality, flow rate and ground area (connect us for more details).
Q:How to pay?
A:TT,Western Union and MoneyGram paypal, etc. 30% deposit before producing, 70% balance before loading by TT.
Q:What is the delivery time?
A:It depends on order quantities. Generally speaking, the delivery time will be within 35 days after payment.
Q:How to pack the products?
A:Wooden package usually.
Q:How to install after the equipments arriving destination?
A:We will provide detailed illustrations to you. If it is necessary, we will send technicians to help you
.
