Quick Details
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
2206mm*1160mm*1233mm
-
Machine Weight:
-
830 kg
-
Engine power:
-
23HP
-
Engine:
-
Briggs & Stratton Engine
-
Operation Weight:
-
890kg
-
Operating Load:
-
200kg
-
Bucket capacity:
-
0.15m3
-
Attachments:
-
digger, backhoe, fork,grapple,trencher,lown mower,auger drill .etc
-
Color:
-
Yellow or Customize
-
Engine Warranty:
-
3 years
-
Keyword:
-
mini loader
Quick Details
-
Engine Brand:
-
Briggs & Stratton
-
Power:
-
17.2 kw
-
Brand Name:
-
HYSOON
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
2206mm*1160mm*1233mm
-
Machine Weight:
-
830 kg
-
Engine power:
-
23HP
-
Engine:
-
Briggs & Stratton Engine
-
Operation Weight:
-
890kg
-
Operating Load:
-
200kg
-
Bucket capacity:
-
0.15m3
-
Attachments:
-
digger, backhoe, fork,grapple,trencher,lown mower,auger drill .etc
-
Color:
-
Yellow or Customize
-
Engine Warranty:
-
3 years
-
Keyword:
-
mini loader
HYSOON mini skid steer loader, wheel loader, mini dumper
|
Items |
Mini skid steer loader HY380 |
|
|
With engineer tyre |
||
|
Metric |
U.S |
|
|
Max Pin Height(B) |
1884mm |
74.17inch |
|
Max Working Height(A) |
2143mm |
84.37inch |
|
Max Dump Height(C) |
1488mm |
58.58inch |
|
Max Dump Distance(D) |
348mm |
13.7inch |
|
Total Height(H) |
1233mm |
48.54inch |
|
Overall Length (L) |
2206mm |
86.9inch |
|
Overall Length without bucket(J) |
1752mm |
69.0inch |
|
Bucket Width(K) |
980mm |
38.6inch |
|
Total Width(W) |
1160mm |
45.67inch |
|
Ground Clearance(F) |
118mm |
4.65inch |
|
Wheel Base(G) |
636mm |
25.0inch |
|
Departure Angle(α) |
11° |
11° |
|
Max Dumping Angle (γ) |
30° |
30° |
|
Rollback of bucket on ground(θ) |
25° |
25° |
|
Turn Radius forward turning(R) |
1307 |
51.5inch |
|
Engine |
||
|
Rated Power (KW) |
17.1KW |
|
|
Rotating Speed |
3600rpm |
|
|
Noise(Dd) |
≤95 |
|
|
Hydraulic System |
||
|
Pressure |
17Mpa |
|
|
Working Time(s) |
||
|
Raise |
4.27 |
|
|
Dump |
1.34 |
|
|
Lower |
3.31 |
|
|
Operating Load |
200kg |
441Lb |
|
Bucket Capacity |
0.15m³ |
5.33ft³ |
|
Max Lifting Force |
375kg |
827Lb |
|
Travel Speed |
0-5.5km/h |
0-3.4 mile/h |
|
Operating Weight |
890kg |
1958lb |
• Parts: Gear pump and imported Italy multi-way valve
• Tires: Engineer tires. For optional: solid tires, grass tires, crawler
• Optional configuration: servo system.(joystick)
• 360° steering. Flexible and operating easily.
• Compact design can for any small space working.
• A loader serves several functions. Chinese Mini skid steer loader HY380 can with various attachment for different working need.
• Quick hitch system makes fastening attachments quickly and eaily.
• Balance weight platform optional.
• Diesel engine and electric configuration optional.
• Global famous brand engine, supply international warranty service for 3 years.
• With different attachments, HYSOON hot small skid steer loader for sale can be multifunctional.
A loader serves several purposes.With a quick hitch system, the Mini skid steer loader HY380 can change various attachments for different function quickly and easily. Attachments: backhoe, digger, sweeper, dump bucket, tiller, lawn mower, angle blade, breaker, 4 in 1 bucket,snow blower, leveler, lawn aerator, trench filler, trencher, grapple, auger, stone bucket, anger levers, Standard bucket, trailer system, and so on.
Taian Hysoon Machinery Co.,Ltd
|
1 |
Chinese Professional skid steer loader manufacturer. 12 year skid steer loader development experience. |
|
2 |
Direct factory price. Offer you the product with the high cost performance. |
|
3 |
Good quality: Original products and OEM services, with all needed Certifications. |
|
4 |
Independent of The Design Team, Professional Production Team, 15 Technical Patents. Acce |
|
5 |
Responsible, in Good Faith. To Guarantee Delivery. Do Security by Alibaba Escrow. |
|
6 |
Four series of products: MIni skid steer loader, skid steer loader, mini wheel loader and mini dumper. |
