Quick Details
-
Productivity:
-
22M³/H
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Yugong
-
Weight:
-
1600 kg, 1600kg
-
Dimension(L*W*H):
-
3400*1200*1600mm
-
Product name:
-
concrete mortar spray mixer pump diesel
-
Power:
-
22KW
-
Maximum outlet pressure:
-
15/18mpa
-
Max Aggregate Size:
-
20mm
-
Horizontal conveying distance:
-
40m
-
Vertical conveying distance:
-
80m
-
Dimension:
-
3400*1200*1600mm
Quick Details
-
Power Type:
-
Diesel
-
Max. vertical conveying distance:
-
120M
-
Max. horizontal conveying distance:
-
260M
-
Productivity:
-
22M³/H
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Yugong
-
Weight:
-
1600 kg, 1600kg
-
Dimension(L*W*H):
-
3400*1200*1600mm
-
Product name:
-
concrete mortar spray mixer pump diesel
-
Power:
-
22KW
-
Maximum outlet pressure:
-
15/18mpa
-
Max Aggregate Size:
-
20mm
-
Horizontal conveying distance:
-
40m
-
Vertical conveying distance:
-
80m
-
Dimension:
-
3400*1200*1600mm
Concrete pump
Product Description
The concrete pump is composed of a pump body and a delivery pipe. It is a machine that uses pressure to continuously transport concrete along pipelines. It is mainly used in construction of houses, bridges and tunnels.
Specification
| Model | YG-10 | YG-20 | YG-30 | YG-40 |
| Power | 15kw | 22kw | 37kw | 45kw |
| Max outlet pressure | 15mpa | 15/18mpa | 15/18mpa | 23mpa |
| Max theoretical throughput | 6m³/h | 12m³/h | 15-18m³/h | 20-22m³/h |
| Max aggregate size | 15mm | 20mm | 20mm | 20mm |
| Horizontal conveying distance | 30m | 40m | 160m | 260m |
| Vertical conveying distance | 20m | 80m | 80m | 120m |
| Weight | 600kg | 1600kg | 2200kg | 2400kg |
| Dimension | 1800*700*1100mm | 3400*1200*1600mm | 3800*1500*1600mm | 4000*1500*1600mm |
Packaging & Shipping
1. Packaging:
Packed by standard import & export wooden cases or carton boxes.
2. Shipping:
By logistics; by automobile; by train; by shipping; by air etc.
