Quick Details
-
Brand Name:
-
Wingo, GSO
-
Model Number:
-
GBP48-200W, GBP48-200W
-
Place of Origin:
-
Anhui, China
-
Weight:
-
88kg
-
The charging ratio:
-
100
-
The discharge rate:
-
50
-
Electric Energy:
-
10000 Wh
-
Battery Type:
-
Lithium Ion
-
Voltage:
-
48V
-
Cycle life:
-
>5000 times
-
Nominal Capacity:
-
200ah
-
Certification:
-
CE/RoHS/UN38.3/MSDS
-
Protection:
-
IP20
-
Communication:
-
CAN/RS485
-
Usage:
-
Power storage
Quick Details
-
Storage Type:
-
Power storage
-
Anode Material:
-
LFP
-
Application:
-
BOATS, Golf Carts, electric vehicles, Solar Energy Storage Systems, RV Systems
-
Brand Name:
-
Wingo, GSO
-
Model Number:
-
GBP48-200W, GBP48-200W
-
Place of Origin:
-
Anhui, China
-
Weight:
-
88kg
-
The charging ratio:
-
100
-
The discharge rate:
-
50
-
Electric Energy:
-
10000 Wh
-
Battery Type:
-
Lithium Ion
-
Voltage:
-
48V
-
Cycle life:
-
>5000 times
-
Nominal Capacity:
-
200ah
-
Certification:
-
CE/RoHS/UN38.3/MSDS
-
Protection:
-
IP20
-
Communication:
-
CAN/RS485
-
Usage:
-
Power storage
Product Description
Specification
|
Model
|
GBP48V-50W
|
GBP48V-100W
|
GBP48V-200W
|
||
|
Nominal voltage（V）
|
48
|
|
|
||
|
Nominal capacity (AH)
|
50
|
100
|
200
|
||
|
Working voltage range
|
42-56.25
|
|
|
||
|
Recommend charging volt（V）
|
52
|
|
|
||
|
Working voltage range
|
42-56.25
|
|
|
||
|
Standard charging current(A)
|
25
|
50
|
50
|
||
|
Max. Constant charging current(A)
|
50
|
100
|
100
|
||
|
Standard discharging current（A）
|
25
|
50
|
50
|
||
|
Max. Discharging current（A）
|
50
|
100
|
100
|
||
|
Temperature（℃）
|
-30℃～60℃(Recommend 10℃～35℃)
|
|
|
||
|
Allowable humidity range
|
0～85% RH
|
|
|
||
|
Storage temperature（℃）
|
-20℃～65℃(Recommend 10℃～35℃)
|
|
|
||
|
Protection
|
IP20
|
|
|
||
|
Cooling method
|
Natural air cooling
|
|
|
||
|
Maximum Dimension（W*D*H）for power wall
|
410*640*195
|
|
|
||
|
Net Weight (KG)
|
25
|
50
|
90
|
||
