Meeblue is a creative technology design and development company based in Shenzhen China. Having developed a variety of smart
bluetooth solutions across different industries, we are devoted to IOT solutions and indoor navigation flied. We are focused on
R&D and manufacture mobile Internet technology products, including hardware production, firmware building, software development and electronics engineering.
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
Meeblue
-
Supplier Type:
-
Supplier
-
Product name:
-
Wireless Temperature Humidity Sensor WiFi Hygrometer WiFi Beacon
-
Signal Distance:
-
150m(492 feet) in open sapce
-
BLE version:
-
5.0
-
Size:
-
43.7mm*43.7mm*14.8mm
-
Battery life:
-
24 months based on broadcasting rate 1s'
-
Transmission interveral:
-
100ms to 10.24s can be configured
-
Tool app:
-
Checkblue
-
Compatible:
-
IOS and Android
-
Function:
-
iBeacon and Eddystone
-
Certification:
-
CE FCC RoHS
Quick Details
-
Chipset:
-
nRF 52
-
Application:
-
iBeacon and Eddystone
-
Model Number:
-
M52-PA-S
-
Place of Origin:
-
China
-
Brand Name:
-
Meeblue
-
Supplier Type:
-
Supplier
-
Product name:
-
Wireless Temperature Humidity Sensor WiFi Hygrometer WiFi Beacon
-
Signal Distance:
-
150m(492 feet) in open sapce
-
BLE version:
-
5.0
-
Size:
-
43.7mm*43.7mm*14.8mm
-
Battery life:
-
24 months based on broadcasting rate 1s'
-
Transmission interveral:
-
100ms to 10.24s can be configured
-
Tool app:
-
Checkblue
-
Compatible:
-
IOS and Android
-
Function:
-
iBeacon and Eddystone
-
Certification:
-
CE FCC RoHS
Meeblue Profile
Product Description
M52-PA-S is a Bluetooth temperature & humidity sensor beacon with high accuracy and long range .
With SHT31 sensor, the typical tolerance of temperature is ±0.5℃/32.9℉,and the typical tolerance of relative humidity is ±2%RH.
With power amplifier, the Bluetooth range can reach 492 feet which can greatly meet the needs of users in a variety of different occasions.
And our tool app CheckBlue supports to check real-time and historical Temp/RH data.
Device parameters can be adjustable, like TX power, broadcast interval and so on.
We support firmware OTA through our tool app CheckBlue in IOS system. Also SDKs for IOS and Android are available.
M52-PA-S WHITE
M52-PA-S BLACK
Product Specifications
|
|
Values
|
Remarks
|
|
Chipset
|
Nordic52810 QFAA
|
|
|
Sensitivity
|
-96dB in BLE mode
|
|
|
Power supply
|
1.7V-3.6V
|
|
|
Battery
|
CR2477 Coin battery
|
|
|
4Signal distance
|
492 feet in open air
|
|
|
Demensions
|
43.7mm*43.7mm*14.8mm
|
|
|
Weight
|
25g
|
|
|
Antena
|
On board
|
|
|
LED
|
RGB
|
|
|
Humidity and Temperature sensor
|
SHT31
|
|
|
Housing material
|
ABS
|
|
|
Waterproof
|
NO. (Waterproof flim available if needed.)
|
|
|
Button
|
Yes
|
|
Default Parameters
|
Beacon state
|
Sleep Mode
|
|
Beacon name
|
meeblue
|
|
Password
|
meeble
|
|
TX power
|
0dB
|
|
Broadcast interval
|
100ms
|
|
UUID
|
EBEF083-70A2-47C8-9837-E7B5634DF524
|
|
Major
|
1
|
|
Minor
|
1
|
|
Firmware
|
1.0
|
Support
|
Tool app
|
CheckBlue
|
|
SDK or Demo
|
ios and Android
|
|
Update
|
OTA
|
