Quick Details
-
Brand Name:
-
DINOS
-
Place of Origin:
-
zhejiang
-
Model Number:
-
DB25
-
Battery Model:
-
12V/6A Nanometer Colloid Battery
-
dirt bike Engine:
-
Four-stroke
-
Transmission Ratio:
-
520/13T-47T Manganese Steel Sprocket, 520H Chain
-
Tires - FT:
-
80/100-21 Knobby Off Road Tire
-
Tires - RR:
-
110/100-18 Knobby Off Road Tire
-
L x W x H:
-
2160X810X1260mm
-
Vehicle Weight:
-
106kg
-
Seat Hight:
-
900mm
-
Minimum Ground Clearance:
-
300mm
-
Fuel Tank Volume:
-
6.5L
Quick Details
-
Displacement:
-
200-400CC
-
Max. Speed:
-
> 80km/h
-
Motor:
-
Brushless
-
Brand Name:
-
DINOS
-
Place of Origin:
-
zhejiang
-
Model Number:
-
DB25
-
Battery Model:
-
12V/6A Nanometer Colloid Battery
-
dirt bike Engine:
-
Four-stroke
-
Transmission Ratio:
-
520/13T-47T Manganese Steel Sprocket, 520H Chain
-
Tires - FT:
-
80/100-21 Knobby Off Road Tire
-
Tires - RR:
-
110/100-18 Knobby Off Road Tire
-
L x W x H:
-
2160X810X1260mm
-
Vehicle Weight:
-
106kg
-
Seat Hight:
-
900mm
-
Minimum Ground Clearance:
-
300mm
-
Fuel Tank Volume:
-
6.5L
Details Images
Specification
|
Engine
|
|
|
|
Name
|
ZONGSHEN 4-stroke CBS300
|
|
|
Model
|
CBS-300-01
|
|
|
Type
|
Single-cylinder, 4-stroke, Water-cooled, 4-valve, Overhead double cam
|
|
|
Maximum Power
|
18.5Kw/8500
|
|
|
Maximum Torque
|
23N.m/7000
|
|
|
Compression Ratio
|
10.7: 1~11.3: 1
|
|
|
Bore
|
74mm
|
|
|
Start Method
|
Electric+Kick Start
|
|
|
Ignition Method
|
C.D.I.
|
|
|
Clutch Type
|
Wet Multi-Plate
|
|
|
Gearshift Method
|
Constant mesh with two-stage transmission and five-speed transmission
|
|
|
Fuel Delivery
|
PWK34 Carburetor
|
|
|
Lubrication method
|
Pressure Splash
|
|
|
Frame
|
|
|
|
Length × Width × Height
|
2170×840×1290mm
|
|
|
Seat Height
|
960mm
|
|
|
Minimum Ground Clearance
|
315mm
|
|
|
Wheelbase
|
1470mm
|
|
|
Vehicle Weight
|
118kg
|
|
|
Fuel Tank Capacity
|
8L
|
|
|
Maximum Speed
|
95Km/h
|
|
|
Gearshift Method
|
Internatioal 5-speed Gearshift.
|
|
|
Tire Specifications (Front/Rear)
|
80/100-21 / 110/100-18
|
|
|
Tire Pressure (Front/Rear)
|
225Kpa / 335Kpa
|
|
|
Brake Method (Front/Rear)
|
Disc Brake / Disc Brake
|
|
|
Rim Specifications (Front/Rear)
|
1.6×21 / 2.15×18
|
|
|
Suspension System
|
CNC up and down resistance adjustable front shock absorber
|
|
|
|
Single cylinder hydraulic built-in central airbag rear shock absorber
|
|
Exhibition
Packing & Delivery
To make sure our products will be delivered to our customers undamaged, every package method needs to go through impact test. We are to be sure no customers will suffer loss from shipping.
