2. 30 Years Drilling Rig Production And Marketing
3.With High Quality , First-Class Services And Reasonable Prices .
4. One year remote warranty service , (parts delivery, fault diagnosis, online guidance).
- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
2500mm*1100mm*2400mm
-
Weight:
-
1200 KG
-
Marketing Type:
-
Hot Product 2023
-
Drilling Diameter:
-
75-300mm
-
Drilling Depth:
-
Max.150m
-
Mobility:
-
wheels trailer
-
Water Well Drilling Rig:
-
Water Well Drilling Rig
-
Max. Drilling Depth:
-
150m
-
Diesel Engine:
-
32HP
-
Capacity of hoist:
-
3T
-
Height of tower:
-
2.5m
-
Measurement:
-
2500mm*1100mm*2400mm
-
Total Weight:
-
1200kgs
-
Drilling Rod Length:
-
2.0m/piece
-
Mud Pump:
-
75m³/h Head: 75m
-
Capacity of Lifting:
-
3000kg
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
AKL
-
Voltage:
-
32HP
-
Dimension(L*W*H):
-
2500mm*1100mm*2400mm
-
Weight:
-
1200 KG
-
Marketing Type:
-
Hot Product 2023
-
Drilling Diameter:
-
75-300mm
-
Drilling Depth:
-
Max.150m
-
Mobility:
-
wheels trailer
-
Water Well Drilling Rig:
-
Water Well Drilling Rig
-
Max. Drilling Depth:
-
150m
-
Diesel Engine:
-
32HP
-
Capacity of hoist:
-
3T
-
Height of tower:
-
2.5m
-
Measurement:
-
2500mm*1100mm*2400mm
-
Total Weight:
-
1200kgs
-
Drilling Rod Length:
-
2.0m/piece
-
Mud Pump:
-
75m³/h Head: 75m
-
Capacity of Lifting:
-
3000kg
Product Description
Why Choose Us
1 .
Factory Store
, Large Production Capacity , Provide
OEM & ODM SERVICE
.
2. 30 Years Drilling Rig Production And Marketing
3.With High Quality , First-Class Services And Reasonable Prices .
4. One year remote warranty service , (parts delivery, fault diagnosis, online guidance).
2. 30 Years Drilling Rig Production And Marketing
3.With High Quality , First-Class Services And Reasonable Prices .
4. One year remote warranty service , (parts delivery, fault diagnosis, online guidance).
|
SPECIFICATION
|
|
|
||
|
Typec
|
AKL-150Y+
|
|
||
|
Drilling Capacity
|
Diameter 300mm
|
30-40m Depth
|
||
|
|
Diameter 150mm
|
100-150m Depth
|
||
|
Diesel Engine
|
32HP Key Start Diesel
|
|
||
|
Capacity of Lifting
|
3000kg
|
|
||
|
Mud Pump
|
75m³/h Head: 75m
|
|
||
|
Rotary Speed
|
70-90rpm
|
|
||
|
Height of Tower
|
2.5m
|
|
||
|
Measurement
|
2.5*1.1*2.3m
|
|
||
|
Total Weight
|
1200kgs
|
|
||
|
Drilling Rod Length
|
2m/piece
|
|
||
|
Diameter of Drilling Rod
|
60mm
|
|
||
Of Water Well Drilling Rig Machine Applications And Features:
1. This diesel hydraulic water well drilling machine occupies a small area ( 1square meters), a height of 2 meters stand, the job can be installed in less than ten minutes, can be used at indoor and outdoor site.
2. The pipe is fully enclosed, shallow layer has no leakage, can ensure the health and safety of drinking water.
3. This portable water well drilling rig research and develop by ourself, apply to different stratum, such as sand, soil, clay, soft rock and so on.
4. All the lifting, loading and unloading drill pipe is mechanized, time-saving, labor-saving and easy to operate.
5. China best quality with competitive price for sale.
Customer Photos
Advantages :
1. One man can operate, auto water flow control function.
2. Double lift chains, with hydraulic oil radiator.
3. Drilling process is stable, no jamming or shaking.
4. Electric start, it can charge the battery automatically.
5. Thicked and strong water swivel, inlet water pipe can change direction, with the screw to fix the inlet water pipe to ensure there is no water leak.
6. hydraulic oil radiator installed at the top near the hydraulic tank, it can cool the hydraulic oil well, also can prevent accidental collision (if installed below, it is easily crushed during transportation)
Customer Feedback
Learn more about machines
if you want to know the specific price,please contact us or send us inquiry,then we can give you detail quotation list
About Us
Xuchang Shengte Trade Co.,Ltd
as a major
drilling machinery manufacturer in China, is specialized in producing all kinds of water well drilling rigs, drilling rig, and agricultural machinery for more than
30 years
.
Our company is located Henan province, with advantages of convenient transportation and graceful environment. , own modern office facilities and a first-class management term. Currently, our group consists of two main sub companies: Xuchang Shengte Machinery Co.,Ltd for all domestic market and Xuchang Shengte Trade Co.,Ltd. for all oversea market. Here we sincerely welcome our cooperation with you at any time.
Production
Workshop
Xuchang Shengte Machinery Co., Ltd. covers an area of 8 acres, has more than 200 employees, and has an advanced Drilling Rig production line
FAQ
1. who are we?
We are based in Henan, China, start from 2016,sell to Southeast Asia(30.00%),Africa(30.00%),South America(20.00%),Central America(10.00%),North America(10.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Drilling Rig,Construction Machinery,Agricultural Machinery,Electrical Equipment,Exploration Machinery
4. why should you buy from us not from other suppliers?
As a major drilling machinery manufacturer in China, we specialized in producing all kinds of water well drilling rig, exploration drilling rig, pile drilling rig for more than 30 years. and also provide all kinds of agricultural machinery.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,Express Delivery；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish
We are based in Henan, China, start from 2016,sell to Southeast Asia(30.00%),Africa(30.00%),South America(20.00%),Central America(10.00%),North America(10.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Drilling Rig,Construction Machinery,Agricultural Machinery,Electrical Equipment,Exploration Machinery
4. why should you buy from us not from other suppliers?
As a major drilling machinery manufacturer in China, we specialized in producing all kinds of water well drilling rig, exploration drilling rig, pile drilling rig for more than 30 years. and also provide all kinds of agricultural machinery.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,Express Delivery；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish
