Quick Details
-
Brand Name:
-
ZAEE
-
Power:
-
35000 W
-
Dimension(L*W*H):
-
Customized
-
Weight:
-
2000 KG
-
Product name:
-
Needle punching machine
-
After-sales Service:
-
Provide
-
Certificate:
-
CE
-
Service Provided:
-
Free spare parts, Video technical support
-
Name:
-
Computerized electronic jacquard needle loom for wedding carpet
-
Needle density::
-
3500-4500n/m
-
Pipe::
-
Copper sheathing
-
Usage:
-
Home Texitle
Quick Details
-
Voltage:
-
380V
-
Marketing Type:
-
New Product 2022
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
ZAEE
-
Power:
-
35000 W
-
Dimension(L*W*H):
-
Customized
-
Weight:
-
2000 KG
-
Product name:
-
Needle punching machine
-
After-sales Service:
-
Provide
-
Certificate:
-
CE
-
Service Provided:
-
Free spare parts, Video technical support
-
Name:
-
Computerized electronic jacquard needle loom for wedding carpet
-
Needle density::
-
3500-4500n/m
-
Pipe::
-
Copper sheathing
-
Usage:
-
Home Texitle
Product Description
Carpet Making Machine Needle Punched Machine for Wipe Cleaning
|
Product Name
|
NEEDLE PUNCHING MACHINE
|
|
Applicable Industries
|
Manufacturing Plant, Machinery Repair Shops, Other
|
|
Video outgoing-inspection
|
Provided
|
|
Machinery Test Report
|
Provided
|
|
Marketing Type
|
New Product 2021
|
|
Warranty of core components
|
1 Year
|
|
Core Components
|
PLC, Motor
|
|
Condition
|
New
|
|
Automatic Grade
|
Automatic
|
|
Place of Origin
|
China
|
|
Brand Name
|
ZAEE
|
|
Voltage
|
220V
|
|
Power
|
35000W
|
|
Dimension(L*W*H)
|
Customized
|
|
Weight
|
2000KG
|
|
Warranty
|
1 Year
|
|
Key Selling Points
|
Automatic
|
1.Working width: 2700--7200mm
2.Strokes frequency: 1000-1100 strokes/min
3.Moving distance of the stroke: 30mm
4.Density of the needles: 6000 needles/meter
5.Working speed: 0.5-8 meter/min
6.Needles spec: dia of the root: φ1.83mm
Working dia: φ0.4-0.9mm
Total length: 76-89mm
7.Installation power: 28.4kw--54kw
8.Bearings of the oil case body: imported from germany
9.Bottom needle girder up&down: electronic worm wheel up and down, depth of the punching displayed.
Stripping board up&down: hand operation worm wheel up&down
10.Main axle: 400Cr qualitatively treated,Raw material in& out roller, main motor: frequency transducer controlled.
11.Needle board: aluminium & magnesium alloyed
12.Stripping board: 10mm steel board
13.Bottom needle board: 12mm steel board
oil pump circling way: cirdyling outside the oil case
handspike: 38CrMoAL, coated with hard chrome(with dust proof loop)
14. big girder structure: mounted and welded structure
15. steel thickness: 16-30mm
16.vibration deduction way: self-deduction vibration cylinder
17. oil case heat disperse: circling oil self-equipped radiator
18. main axle connecting way: double combined gear wheel, linked axle device.
2.Strokes frequency: 1000-1100 strokes/min
3.Moving distance of the stroke: 30mm
4.Density of the needles: 6000 needles/meter
5.Working speed: 0.5-8 meter/min
6.Needles spec: dia of the root: φ1.83mm
Working dia: φ0.4-0.9mm
Total length: 76-89mm
7.Installation power: 28.4kw--54kw
8.Bearings of the oil case body: imported from germany
9.Bottom needle girder up&down: electronic worm wheel up and down, depth of the punching displayed.
Stripping board up&down: hand operation worm wheel up&down
10.Main axle: 400Cr qualitatively treated,Raw material in& out roller, main motor: frequency transducer controlled.
11.Needle board: aluminium & magnesium alloyed
12.Stripping board: 10mm steel board
13.Bottom needle board: 12mm steel board
oil pump circling way: cirdyling outside the oil case
handspike: 38CrMoAL, coated with hard chrome(with dust proof loop)
14. big girder structure: mounted and welded structure
15. steel thickness: 16-30mm
16.vibration deduction way: self-deduction vibration cylinder
17. oil case heat disperse: circling oil self-equipped radiator
18. main axle connecting way: double combined gear wheel, linked axle device.
AUTO 3-ROLL MIXER
AUTO 3-ROLL MIXER
Why Choose Us
Why Choose ZAEE NONWOVEN ?
1：When you encounter problems, or your equipment needs to be upgraded, we can provide you with the most energy-efficient and reasonable budget solution.
2：If you are a novice in the market, we will provide you with the most professional consulting services and guidance according to your expectations.Make sure you do a test or trial before shipment so that you can witness real-time production and make necessary adjustments
according to your market needs.
3：If you are planning to Increase your production scale, Let us know your requirements ( Intended product, Capacity, Density and Raw material),We avail you the Production layout of the new line for your reference.
1：When you encounter problems, or your equipment needs to be upgraded, we can provide you with the most energy-efficient and reasonable budget solution.
2：If you are a novice in the market, we will provide you with the most professional consulting services and guidance according to your expectations.Make sure you do a test or trial before shipment so that you can witness real-time production and make necessary adjustments
according to your market needs.
3：If you are planning to Increase your production scale, Let us know your requirements ( Intended product, Capacity, Density and Raw material),We avail you the Production layout of the new line for your reference.
