T5H 2.4G Wireless Hyperlink Version Rechargeable PPT Laser Pointer Remote Control

Product Name

T5H 2.4G Wireless Hyperlink Version Rechargeable PPT Laser Pointer Remote Control

Features

1. Bright red laser spot
2. Up to 100 meters wireless range
3. One-touch slide-show control
4. Plug-and-play
5. High compatibility
6. Stylish appearance
7. Compact and portable

Pairing

Power on the device, blue LED will
flash fast. Plug the USB adapter
into computer and wait about 3
seconds. LED stopped flashing,
means pairing succeed.
If the USB dongle mixed, press
Hyperlink and Page Down button,
then plug the USB into device to
repair it.

Button Functions

1. Power:
Power on/off the device
2. Hyperlink(only works in Microsoft
PowerPoint):
Short press to select the text box
of hyperlink.
Long press 3s to open the hyperlink
3. Page up/Full Screen:
Short press to slide page up
Long press 3s to enter/exit
full screen
4. Laser switch:
Long press to turn on laser spot
Release to turn off laser spot
5. Page down/Black Screen:
Short press to slide page down
Long press for 3s to enter/exit
black screen
Note: Black screen function is
only available in full screen mode
6. Windows switch(For Windows
System):
Short press to enter into last program
Long press for 3s to cyclically switch
all current programs

7. Vol+:
Short Press - Volume up
Long press - Previous song
8. Mute:
Short Press - Mute
Long press - Pause/Play
9. Vol-:
Short Press - Volume down
Long press - Next song

Specifications

TTransmitter Technology: 2.4GHz
Radio Frequency
Control distance: ≈50-100m
Laser distance: ≤200m
Laser module: Class 3R
Output power: 3.3mW
Laser wavelength: 650nm
Battery: AAA*1 (not included) /
Li-on battery(built in)
Working Voltage: 3.3V
Size: 140*18*19mm
Weight: 22g(AAA version)/
28g(Rechargeable version)
Supported OS: Windows, Android,
Mac OS, Linux

Safety Warning

Ø 1. Be warned that laser spot should
never under any circumstances be
directed into people and animal's eyes.
2. This product is not a toy and should
not to be used by anyone under 18.
3. It is illegal to direct the laser spot at
any flying objects, moving vehicles
and any public or private structures.
4. The laser spot can be dangerous
if not used properly.
