Product Overview
Description of Industrial Air Cooled Heat Exchanger with Fin Tube
Industrial Air Cooled Heat Exchanger with Fin Tube, or called Air cooler, is an industrial heat exchanger that uses Ambient air as cooling medium, where the fan forces air cross the Finned pipes to cool the high-temperature processing medium within the pipes.
The air cooler is mainly composed of three basic parts: tube bundle, fan and structure, and auxiliary parts like louver and
platform handrails. It uses natural air as cooling medium saving precious water, reducing the discharge of industrial waste water and protecting the natural environment.
Product details
The working principle of the air cooled heat exchanger
Type of Industrial Air Cooled Heat Exchanger with Fin Tube
1. Forced-draft Horizontal Industrial Air Cooled Heat Exchanger with Fin Tube
2. Induced-draft Horizontal Industrial Air Cooled Heat Exchanger with Fin Tube
3. Sloped-top Industrial Air Cooled Heat Exchanger with Fin Tube
2. Induced-draft Horizontal Industrial Air Cooled Heat Exchanger with Fin Tube
3. Sloped-top Industrial Air Cooled Heat Exchanger with Fin Tube
Header Types of Industrial Air Cooled Heat Exchanger with Fin Tube
1. Pipe header
2. Semi-circular bonnet header
3. Cover plate header- for very dirty flows
4. Plug headers-generally the most used
2. Semi-circular bonnet header
3. Cover plate header- for very dirty flows
4. Plug headers-generally the most used
PRODUCT SPECIFICATIONS
|
Tube bundle model
|
Tube
number
|
Pressure
Mpa
|
Tube row number
|
Base tube area,m2
|
Fin area
m2
|
Net weight,
kg
L fin tube
|
Net weight,kg
DR fin tube
|
Water filling weight, kg
|
|
GP12X3-4-172-1.6S-23.4L(DR)-Ia
|
182
|
1.6
|
4
|
172
|
4025
|
7524
|
8529
|
810
|
|
GP12X3-4-172-2.5S-23.4L(DR)-Ia
|
182
|
2.5
|
|
|
|
7563
|
8568
|
|
|
GP12X3-4-172-4.0S-23.4L(DR)-Ia
|
182
|
4
|
|
|
|
7589
|
8594
|
|
|
GP12X3-6-258-1.6S-23.4L(DR)-Ia
|
|
1.6
|
6
|
258
|
6037
|
10408
|
11915
|
1218
|
|
GP12X3-6-258-2.5S-23.4L(DR)-Ia
|
|
2.5
|
|
|
|
10609
|
12116
|
|
|
GP12X3-6-258-4.0S-23.4L(DR)-Ia
|
|
4
|
|
|
|
10939
|
14224
|
|
|
GP12X3-8-344-1.6S-23.4L(DR)-Ia
|
|
1.6
|
8
|
344
|
8049
|
13591
|
15600
|
1625
|
|
GP12X3-8-344-2.5S-23.4L(DR)-Ia
|
|
2.5
|
|
|
|
13590
|
15599
|
|
|
GP12X3-8-344-4.0S-23.4L(DR)-Ia
|
|
4
|
|
|
|
13590
|
15599
|
|
|
GP12X2.5-4-142-1.6S-23.4L(DR)-Ia
|
|
1.6
|
4
|
142
|
3322
|
6474
|
7302
|
668
|
|
GP12X2.5-4-142-2.5S-23.4L(DR)-Ia
|
|
2.5
|
|
|
|
6512
|
7340
|
|
|
GP12X2.5-4-142-4.0S-23.4L(DR)-Ia
|
|
4
|
|
|
|
6534
|
7362
|
|
|
...
|
...
|
...
|
...
|
...
|
...
|
...
|
...
|
...
|
|
GP9X3-4-129-1.6S-23.4L(DR)-Ia
|
|
1.6
|
4
|
129
|
|
5908
|
6661
|
639
|
|
GP9X3-4-129-2.5S-23.4L(DR)-Ia
|
|
2.5
|
|
|
|
5946
|
6700
|
|
|
GP9X3-4-129-4.0S-23.4L(DR)-Ia
|
|
4
|
|
|
|
5972
|
6726
|
|
|
GP9X3-6-193-1.6S-23.4L(DR)-Ia
|
|
1.6
|
6
|
193
|
|
8142
|
9273
|
963
|
|
GP9X3-6-193-2.5S-23.4L(DR)-Ia
|
|
2.6
|
|
|
|
8343
|
9473
|
|
|
GP9X3-6-193-4.0S-23.4L(DR)-Ia
|
|
4
|
|
|
|
8673
|
9803
|
|
|
...
|
...
|
...
|
...
|
...
|
...
|
...
|
...
|
..
|
