Quick Details
-
Application Fields:
-
Outdoor
-
Type:
-
Prefabricated Modular Houses
-
Product name:
-
Quick Assembly Prefabricated House
-
Keyword:
-
Mobile Living Container House
-
Structure:
-
Q 235 B Light Steel Frame
Quick Details
-
Place of Origin:
-
Hebei, China, Hebei, China
-
Brand Name:
-
BAIDA, BaidaMingsheng
-
Product Type:
-
Prefab house
-
Application Fields:
-
Outdoor
-
Type:
-
Prefabricated Modular Houses
-
Product name:
-
Quick Assembly Prefabricated House
-
Keyword:
-
Mobile Living Container House
-
Structure:
-
Q 235 B Light Steel Frame
Product Description
Specification
Item
Specification Size : 5850*2438*2896mm
Part 1 Roof System
I. Steel frame
Steel frame is Q235 galvanized fitting;
Ii. Roof insulation
Ceiling is white color steel pre-coated 0.5mm outside strong steel sheet; With 50mm glass wool insulation material;
Iii. Roof ceiling
Ceiling is shaped steel plate with different pattern
Part 2 Floor System
I. Steel frame
3mm Galvanized Steel for main structure + 1.5mm square tube for secondary beam
Ii. Floor
Specification Size : 5850*2438*2896mm
Part 1 Roof System
I. Steel frame
Steel frame is Q235 galvanized fitting;
Ii. Roof insulation
Ceiling is white color steel pre-coated 0.5mm outside strong steel sheet; With 50mm glass wool insulation material;
Iii. Roof ceiling
Ceiling is shaped steel plate with different pattern
Part 2 Floor System
I. Steel frame
3mm Galvanized Steel for main structure + 1.5mm square tube for secondary beam
Ii. Floor
Fireproof glass magnesium floor 15mm
Part 3 Column System
I Column
2.5mm Shaped Galvanized Steel
Part 4 Sandwich Wall System
I Wall Panel
50mm Fireproof rock wool ; Outside color is light silver gray (0.35mm thickness steel); Inside is white color steel (0.35mm
thickness steel ).
Part 5 Door & window system
I. Door
Material:Steel door
Size:2035*840mm(H*W)
Ii. Window
Material:Aluminum alloy steel double hollow glass
Size:920*1150mm(H*W)
Part 6 Electric system
I. Electric system
Includes ordinary LED light, A-SW double sockets 2 set, A-SW air-switch 2 set,
Electrical box with safety protection device connecting cable for connecting;
Part 7 Accessories
Electric wire;Sealant;Wiring tube;Screws and other accessories.
Part 3 Column System
I Column
2.5mm Shaped Galvanized Steel
Part 4 Sandwich Wall System
I Wall Panel
50mm Fireproof rock wool ; Outside color is light silver gray (0.35mm thickness steel); Inside is white color steel (0.35mm
thickness steel ).
Part 5 Door & window system
I. Door
Material:Steel door
Size:2035*840mm(H*W)
Ii. Window
Material:Aluminum alloy steel double hollow glass
Size:920*1150mm(H*W)
Part 6 Electric system
I. Electric system
Includes ordinary LED light, A-SW double sockets 2 set, A-SW air-switch 2 set,
Electrical box with safety protection device connecting cable for connecting;
Part 7 Accessories
Electric wire;Sealant;Wiring tube;Screws and other accessories.
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Packaging Details
:Stretch film packaging
Port :Tianjin,Tianjin Province/Qingdao,Shandong Province
Port :Tianjin,Tianjin Province/Qingdao,Shandong Province
