Quick Details
-
Panel Dimensions:
-
100*100*100mm
-
Certificate:
-
TUV
-
Connector:
-
PV Solar pannel
Quick Details
-
Cell size:
-
125mmx125mm
-
Type:
-
Half Cell
-
Place of Origin:
-
Hunan, China
-
Panel Dimensions:
-
100*100*100mm
-
Certificate:
-
TUV
-
Connector:
-
PV Solar pannel
mini solar panel 1v 2v 3v 4v 5v 5.5v 9v 12v 18v TUV Top Quality low price Monocrystalline Solar Panel best price hot sell
Technical Specification Data(STC) of Solar Panel
| Model of Solar Panel | RS435M6-144HC | RS440M6-144HC | RS445M6-144HC | RS450M6-144HC | RS455M6-144HC |
| Peak Power Watts-Pmax(Wp)* | 435 | 440 | 445 | 450 | 455 |
| Maximum Power Voltage-Vmpp(V) | 40.8 | 41.0 | 41.2 | 41.4 | 41.6 |
| Maximum Power Current-Impp(A) | 10.67 | 10.74 | 10.81 | 10.88 | 10.95 |
| Open Circuit Voltage-Voc(V) | 48.6 | 48.8 | 49.0 | 49.2 | 49.4 |
| Short Circuit Current-Isc(A) | 11.40 | 11.47 | 11.54 | 11.61 | 11.68 |
| Module Efficiency (%) | 19.6 | 19.8 | 20.0 | 20.2 | 21.4 |
| Power Output Tolerance-Pmax(W) | 0~+5 | ||||
| Temperature Coefficient of Pmax | -0.36%/ºC | ||||
| Temperature Coefficient of Voc | -0.26%/ºC | ||||
| Temperature Coefficient of Isc | 0.05%/ºC | ||||
| STC | Irradiance 1000W/m2, Cell Temperature 25, Air Mass AM1.5 | ||||
Place of Origin: Hunan, China (Mainland)
Brand Name: WEEFA solar connector
Model Number: solar connector
Type: solar
Application: solar, Audio & Video connector
Gender: male and female
Pin dimension: 4MM
Body material: PPO
Contact material: Copper/tin plated
Waterproof degree: IP67
Locking system: Snap in
Certificate: ROHS REACH
Delivery time: 5-7 days
Packaging Details:
Promotion quick fit male female solar panel connector :
1set/polybag,Standard package,
As customer's requirements.
Delivery Detail:
Shipped in 5-7days after payment
| Temperature Range | -40~+90℃(PE Cable -40~+85) | |
| Wire size range | 14/12/410AWG | |
| Current rating | 25AMP | |
| Safety approval | TUV | |
| Protection class | II | |
| Withstanding Voltage | 6 000V AC/minute | |
| Contact Resistance of plug connectors | ≤5mΩ | |
| Flame class | UL94-V0 | |
| Locking system | Snap in | |
| Insulation resistance | ≥1000M Ω | |
| Center Conductor Retention Force | ≥0.28N | |
| Insertion force | ≤50N | |
| Withdraw force | ≥50N | |
| Protection degree | IP67 | |
| Contact plating | Tin plated | |
| Contact material | Copper | |
| Insulator | PPO |
Packing
1). Plastic bag + box + carton
2). Special package requirements acceptable
Terms of Shipping:
1. Products are shipped via UPS / DHL / EMS / HK EMS / FedEx / TNT,by sea,by train ( to Europe)and so on expresses .
2. 5 days delivery upon receiving payment if the qty is lower than 1000PCS and it is not customized products.
3. Shipping via EMS. UPS. FedEx and TNT express usually takes 3~7days,by train 1 month(to Europe) , dependent on the destination country.
4,EXW, FOB, CFR, CIF, DDU, FCA
Warranty:
1.We provide 1 year quality warranty.
FAQ
Why choose us?
1,Timely andeffectiveinquiry response(normal in 12 hours)
2,Located in Changsha , the electronic market center of China.
3,100% guarantee components quality: Genuine Original.
4,Sufficient stock on your urgent demand.
5,Sophisticated sale manager help you solve problems to reduce your risk with on-demand manufacturing
6,24 Hours service
How to Order?
1. Please let us know what kind of model.
2. Proforma invoice (PI) will be sent to you.
3. Please check and confirm the PI.
4. Once we confirmed the order, please pay for soon.
5. After getting your payment, all goods will be sent to you in by sea,by train(to Europe) or air within one month.
6. OEM/ODM is welcomed.
7,FOB (Shanghai,Guanzhou,Changsha)
ABOUT US
Weefa Electronics Co., Limited is located in Changsha City. HuNan Province, P. R. China. Our company is one of the biggest professional exporters and manufacturers in LED electronic ,wire connectors, terminal block, lamp holder, cable gland ,solar connector,solar cable, Nylon cable tie and other related in China for more than 10 years.
Our company attaches great importance to quality control, Our company is always strict with product quality in the process from raw material procurement, production, to production detection. The quality of our product is high and steady in accordance with CE, RoHS. Our products are exported to the Middle East, Southeast Asia, Europe and the America. We also do business of OEM. now are being well sold to more than 60countries all over the world , kind and prompt services to clients.
Offering the best products in most competitive price with the top service is what WEEFA always devote to. With our great success in the international market, we sincerely look forward to establishing a long-term and mutually beneficial partnership with you.
Our philosophy is "top quality, low price". We welcome customers from at home and abroad to call and email us for inquiry. We hope to develop with you together
Let′s get busy and pull together to create a better future!=
Terms of Payment:1. TT ,LC,PayPal, western union,Alibaba Trade Assurance
2. Sample order we accept payment such as paypal, western union ,Visa card ,Alibaba Trade Assurance .
