Quick Details
-
Warranty:
-
1 year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Vlais
-
Model Number:
-
KDE-125T
-
Speed:
-
1500/1800RMP
-
Weight:
-
1850kg
-
Engine model:
-
6BTA5.9-G2/116kw
-
Cylinder Number and Bore*Stroke:
-
6 Cylinder and 102*120 mm
-
Engine type:
-
4 Stroke, Water-cooled, Direct Injection, Vertical, Turbo charge
-
Alternator brand:
-
Stamford, Maratho, Leroy somer
-
Alternator Type:
-
AVR, Self-excitation, Brushless, All copper, single bearing
-
Alternator model:
-
CP-274D/100kw
-
Fuel Consumption at full load:
-
26 L/H
-
Control panel:
-
Deepsea / ComAp / Smartgen 6110
-
Dimension:
-
2800*1180*1800 mm
Quick Details
-
Rated Voltage:
-
110/220V, 220/380V, 230/400V
-
Rated Current:
-
190A
-
Frequency:
-
50/60HZ
-
Warranty:
-
1 year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Vlais
-
Model Number:
-
KDE-125T
-
Speed:
-
1500/1800RMP
-
Weight:
-
1850kg
-
Engine model:
-
6BTA5.9-G2/116kw
-
Cylinder Number and Bore*Stroke:
-
6 Cylinder and 102*120 mm
-
Engine type:
-
4 Stroke, Water-cooled, Direct Injection, Vertical, Turbo charge
-
Alternator brand:
-
Stamford, Maratho, Leroy somer
-
Alternator Type:
-
AVR, Self-excitation, Brushless, All copper, single bearing
-
Alternator model:
-
CP-274D/100kw
-
Fuel Consumption at full load:
-
26 L/H
-
Control panel:
-
Deepsea / ComAp / Smartgen 6110
-
Dimension:
-
2800*1180*1800 mm
Product Description
| The Paramter of Engine | Model: | 6BTA5.9-G2/116kw |
| Displacement and Bore*Stroke: | 5.9L and 102*120 mm | |
| Engine type | 6 Cylinder, 4 Stroke, Direct Injection, Vertical In Line, Electronic governor and Turbo | |
| Start-up | (DC 24V) Electric start | |
| The Parmter of Alternator | Model: | CP-274D/100kw |
| Type: | Self-excitation, AVR, Single Bearing, Brushless and All Copper | |
| Electrical phase connection: | 3 phase 4 wire | |
| Insulation class/Protection class: | H/IP23 | |
| The Paramter of control system | Brand: | Smartagen HGM612UN |
| High water temperature protection: | Yes | |
| High and low voltage/frequency: | Yes | |
| Low oil pressure pretection: | Yes | |
